Форм-фактор
|
mATX |
Габариты
|
9.6'' x 9.6'' (24.4 cm x24.4 cm) |
CPU
|
Intel® Xeon® E3-1200 v5/v6 Series Processors
BIOS version 2.0 or above is required for v4 series |
Чипсет
|
Intel® C236 |
Емкость
|
4 x DDR4 DIMM slots |
Тип
|
Dual Channel DDR4 memory technology
Supports DDR4 2400*/2133/1866/1600 ECC/non-ECC UDIMM memory
|
DIMM Size Per DIMM
|
Supports DDR4 2133 ECC/U DIMM memory
ECC and non-ECC UDIMM : 16GB, 8GB, 4GB
Max. capacity of system memory:64 GB |
Напряжение
|
1.2V |
PCIe 3.0 x 16
|
1 slot(PCIE4/6: x0/x16, x8/x8 ) |
PCIe 3.0 x 8
|
1 slot(PCIE4: x8/x0) |
PCIe 3.0 x 4
|
1 slot (PCIE7 : shared with M.2) |
PCIe 3.0 x 1
|
1 slot |
Контроллер SATA
|
C236: 8x SATA3 6Gb/s (1 port support SATA DOM), support RAID 0,1,5,10 |
Интерфейс
|
1000 /100 /10 Mbps |
Контроллер LAN
|
2 x RJ45 GLAN by Intel® i210
Supports Wake-On-LAN
Supports Energy Efficient Ethernet 802.3az
Supports Dual LAN with Teaming function(TBD)
Supports PXE
LAN1 Supports NCSI |
Контроллер BMC
|
ASPEED AST2400 |
IPMI Dedicated GLAN
|
1 x Realtek RTL8211E for dedicated management GLAN |
Функции
|
Watch Dog
NMI
|
Контроллер
|
ASPEED AST2400 |
VRAM
|
DDR3 16MB |
Порт VGA
|
1 x D-Sub |
Порты USB 3.0
|
4 |
Порт Lan
|
RJ45: 2x GLAN(by Intel® i210)
LAN Ports with LED (ACT/LINK LED and SPEED LED) |
Dedicate LAN
|
RT8211E |
Последовательный порт
|
1(COM1) |
UID Button/UID LED
|
1 |
SATA DOM
|
1 |
M.2
|
1 |
Auxiliary Panel Header
|
1 (include chassis intrusion, location button & LED, front LAN LED, event log LED) |
TPM
|
1 |
IPMB
|
1 |
Зуммер
|
1 |
Вентилятор
|
6(1CPU/3Front/2Rear) |
Питание ATX
|
1x (24-pin) + 1x (8-pin) |
USB 3.0 Header
|
1 ( 2 port ) |
USB 2.0
|
1 ( 2 port ) |
Порт USB 3.0 тип А
|
1 |
Тип BIOS
|
128Mb AMI UEFI Legal BIOS |
Особенности BIOS
|
Plug and Play (PnP)
ACPI 2.0 Compliance Wake Up Events
SMBIOS 2.8.0 Support
ASRock Rack Instant Flash |
Температура
|
CPU Temperature Sensing
System Temperature Sensing
System Inlet Temperature Sensing |
Вентилятор
|
CPU/Rear/Front Fan Tachometer
CPU Quiet Fan (Allow CPU Fan Speed Auto-Adjust by CPU Temperature)
CPU/Rear/Front Fan Multi-Speed Control |
Напряжение
|
Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, 1.0V_M, +BAT, 3VSB, 5VSB |
Watchdog
|
Yes |
ОС
|
Microsoft® Windows®
Linux |
Температура
|
Operation temperature Range: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C |
