Серверная материнская плата Supermicro MBD-X10DAC-O

Supermicro MBD-X10DAC-O

1. Dual socket R3 (LGA 2011) supports Intel® Xeon® processor E5-2600 v4/v3 family; QPI up to 9.6GT/s

2. Intel® C612 chipset

3. Up to 2TB^† ECC 3DS LRDIMM , up to DDR4- 2400^†MHz ; 16x DIMM slots

4. 3 PCI-E 3.0 x16, 2 PCI-E 3.0 x8, and 1 PCI-E 2.0 x4 (in x8) slot

5. Dual GbE LAN ports via Intel® i210

6. 10x SATA3 (6Gbps) ports w/ Intel C612 controller; RAID 0, 1, 5, 10

7. 8x SAS3 (12Gbps) ports w/ Broadcom 3008 controller; SW RAID 0, 1, 10

8. 6x USB 3.0 (4 rear, 2 via header)
    5x USB 2.0 (2 rear, 2 via header, 1 Type A)

9. 7.1 HD Audio with optical S/PDIF

10. Thunderbolt Add-On Card support
