HPE Aruba Networking ClearPass OnBoard Software QuickSpecs

Automated mobile device provisioning and configuration for secure BYOD

ClearPass Onboard automatically configures and provisions mobile devices - Windows desktop, macOS, iOS, Android, Chromebook, and Ubuntu - enabling them to securely connect to enterprise networks in support of BYOD initiatives.

IT can automatically give employees, contractors and partners permission to self-configure their personal devices. The ClearPass Onboard portal dynamically detects a device's operating system and guides the user through the appropriate steps.

This provides an incredibly simple way to configure wireless, wired and VPN settings, apply unique per device certificates and profiles and ensure that users can securely connect their devices to 802.1X- enabled networks with minimal IT interaction.

ClearPass Onboard also increases the amount of usable context for troubleshooting, user- and device-based policies and compliance reporting per each device.

The result is a streamlined workflow that allows IT helpdesk personnel to efficiently automate multiple processes that are required to successfully carry out BYOD initiatives while offloading IT and improving the user experience.

Key Features

- Enables users to self-register and securely onboard multiple devices

- Supports Windows, macOS, iOS, Android, Chromebook and Ubuntu operating systems

- Sponsor-based onboarding allows for custom workflows

- Active Directory and cloud identity credential authentication supported

- Automates the configuration of network settings for wired and wireless endpoints

- Unique provisioning and revocation of device- specific credentials and certificates

- Contains built-in certificate authority specifically for BYOD

- Uses profiling to identify device type, manufacturer and model

- Provides BYOD visibility and centralized policy management capabilities

The ClearPass Advantage

With the industry's most advanced auto-provisioning features, onboarding thousands of devices is amazingly simple via integrated policy management, customizable user-facing portal and built-in certificate authority (CA).

Automated policy management
With ClearPass, IT can use context collected during onboarding to enforce device type and ownership-based network access policies. Centrally-defined policies also limit the types of devices that can be on-boarded and define which user groups can onboard devices..

Built-in certificate authority simplifies administration for BYO devices

Flexible workflow options

The onboard configuration process can be managed via IT-enabled and sponsor required workflows. User authentication can prompt for active directory or cloud identity credentials.

Customized device provisioning

A centrally managed administrator portal allows IT to configure device certificates and trust details, network access, VPN, and health check settings and authentication protocols for wireless and wired networks.

The IT staff can also define the number of devices that can be on-boarded per user and how long their certificates are valid.

Advanced Onboarding Capabilities

Built-in certificate authority for BYOD

The distribution of published device credentials through ClearPass Onboard's built-in CA safeguards organizations that want to adopt BYOD initiative's without requiring the implementation of an external CA. ClearPass Onboard issued certificates are unique as they also include specific user and device context.

The Onboard CA provides the option to utilize certificate management without the need to make changes to an internal public key infrastructure (PKI) or active directory (AD).

ClearPass also supports the distribution of Onboard generated certificates requested by third-party applications - EMM/MDM using SCEP and EST (RFC 7030) proto

Revocation of unique certificates

Easy-to-use search and menu-driven capabilities ensure the rapid revocation and deletion of certificates for specific mobile devices if a user leaves a organization or the mobile device is lost or stolen.

Online Certificate Status Protocol (OCSP) supported.

Ordering Guidance

ClearPass Onboard can be ordered via perpetual license or subscription that includes HPE Aruba Networking Care for the length of the subscription.

Ordering ClearPass Onboard involves the following steps:

1. Determine the number of unique users you will provision within your environment.
2. Select the total number of OnBoard licenses.

Additional Onboard capacity can be purchased at any time to meet growth demands.  ClearPass Onboard is licensed on a per user basis.

Ordering Information

Perpetual Licenses

Description

SKU

HPE Aruba Networking ClearPass - Onboard License 100 Users E-LTU

JZ436AAE

HPE Aruba Networking ClearPass - Onboard License 500 Users E-LTU

JZ437AAE

HPE Aruba Networking ClearPass - Onboard License 1K Users E-LTU

JZ438AAE

HPE Aruba Networking ClearPass - Onboard License 2500 Users E-LTU

JZ439AAE

HPE Aruba Networking ClearPass - Onboard License 5K Users E-LTU

JZ440AAE

HPE Aruba Networking ClearPass - Onboard License 10K Users E-LTU

JZ441AAE

Perpetual Licenses Warranty

90 days

Subscription Licenses (1 Year)

HPE Aruba Networking ClearPass - Onboard License 100 Users 1-year Subscription E-STU

JZ445AAE

HPE Aruba Networking ClearPass - Onboard License 500 Users 1-year Subscription E-STU

JZ446AAE

HPE Aruba Networking ClearPass - Onboard License 1K Users 1-year Subscription E-STU

JZ447AAE

HPE Aruba Networking ClearPass - Onboard License 2500 Users 1-year Subscription E-STU

JZ448AAE

HPE Aruba Networking ClearPass - Onboard License 5K Users 1-year Subscription E-STU

JZ449AAE

HPE Aruba Networking ClearPass - Onboard License 10K Users 1-year Subscription E-STU

JZ450AAE

HPE Aruba Networking ClearPass - Onboard License 100 Users 3-year Subscription E-STU

JZ454AAE

HPE Aruba Networking ClearPass - Onboard License 500 Users 3-year Subscription E-STU

JZ455AAE

HPE Aruba Networking ClearPass - Onboard License 1K Users 3-year Subscription E-STU

JZ456AAE

HPE Aruba Networking ClearPass - Onboard License 2500 Users 3-year Subscription E-STU

JZ457AAE

HPE Aruba Networking ClearPass - Onboard License 5K Users 3-year Subscription E-STU

JZ458AAE

HPE Aruba Networking ClearPass - Onboard License 10K Users 3-year Subscription E-STU

JZ459AAE

HPE Aruba Networking ClearPass - Onboard License 100 Users 5-year Subscription E-STU

JZ463AAE

HPE Aruba Networking ClearPass - Onboard License 500 Users 5-year Subscription E-STU

JZ464AAE

HPE Aruba Networking ClearPass - Onboard License 1K Users 5-year Subscription E-STU

JZ465AAE

HPE Aruba Networking ClearPass - Onboard License 2500 Users 5-year Subscription E-STU

JZ466AAE

HPE Aruba Networking ClearPass - Onboard License 5K Users 5-year Subscription E-STU

JZ467AAE

HPE Aruba Networking ClearPass - Onboard License 10K Users 5-year Subscription E-STU

JZ468AAE

Notes:

- Subscription and enterprise licenses can be purchased in 1-, 3- or 5-year increments for 100, 500, 1,000, 2,500, 5,000, and 10,000 endpoints.

- Extended with support contract

Date

Version History

Action

Description of Change

27-Feb-2026

Version 7

Changed

Rebranding update applied to QuickSpecs

16-Dec-2024

Version 6

Changed

Overview section was updated

12-Feb-2024

Version 5

Changed

Networking product names were updated

18-Dec-2017

Version 4

Changed

Product overview, Advanced Onboarding Capabilities, Ordering Guidance and Ordering Information updated

04-Dec-2017

Version 3

Changed

SKUs added: JZ436AAE, JZ437AAE, JZ438AAE, JZ439AAE, JZ440AAE, JZ441AAE, JZ445AAE, JZ446AAE, JZ447AAE, JZ448AAE, JZ449AAE, JZ450AAE, JZ454AAE, JZ455AAE, JZ456AAE, JZ457AAE, JZ458AAE, JZ459AAE, JZ463AAE, JZ464AAE, JZ465AAE, JZ466AAE, JZ467AAE, JZ468AAE

All document sections updated

16-Oct-2017

Version 2

Changed

HPE Aruba Networking information updated

01-Nov-2016

Version 1

Created

Document creation.
