HPE Smart Array P430 Controller

The HPE Smart Array P430 Controller is a low profile, PCIe3 x8, 12Gb/s capable Serial Attached SCSI (SAS) RAID controller that provides enterprise class storage performance and data protection for select HPE ProLiant Gen8 rack and tower servers. It features eight internal physical links and delivers increased server uptime by providing advanced storage functionality, including online RAID level migration (between any RAID levels) with flash back write cache, global online spare, and pre-failure warning. Data compatibility between HPE Smart Array Controllers means customers can easily upgrade to future Smart Array Controllers.

What's New

• HPE Smart Array P430 controller with 4GB Flash Backed Write Cache kit with battery
• HPE Secure Encryption is supported on P430 as an option
• 12Gb/s SAS performance when used on a DL580 Gen8 with 12Gb/s devices (SSDs or HDDs)

Models

HPE Smart Array P430 Controller

HPE Smart Array P430/2GB FBWC 12Gb 1-port Int SAS Controller

698529-B21

The Smart Array Advantage

HPE's innovative design and integration work of the Smart Array family of products creates customer value that is unmatched in the industry. Use of Smart Array products across multiple applications results in a much lower Total Cost of Ownership (TCO) than any other server storage RAID product. The HPE Smart Array family brings an unparalleled return on investment through:

Data Compatibility among most current shipping Smart Array controllers allows simple and easy upgrades any time as needs for higher performance, capacity, and availability increase. Even successive generations of Smart Array controllers understand the data format of other Smart Array Controllers.

Consistent Configuration and Management Tools. Most current shipping Smart Array products utilize a standard set of management and utility software. These tools minimize Total Cost of Ownership (TCO) by reducing training requirements and technical expertise necessary to install and maintain the HPE server storage.

SmartDrive Carrier form factor is used across multiple Hewlett Packard Enterprise servers. With compatibility across many enterprise platforms, you are free to deploy and re-deploy these drives to quickly deliver increased storage capacity, migrate data between systems, and easily manage spare drives.

Pre-Failure Warranty means HPE Insight Manager not only reports when a drive is going to fail but allows replacement of failing drives prior to actual failure. For complete details, consult the HPE Support Center or refer to your HPE Server documentation.

Key Features

• The SA-P430 Controller supports up to 27 drives depending on the server implementation.
• Seamless upgrades from past generations and upgrades to next generation HPE high performance and high capacity Serial Attached SCSI Smart Array controllers.
• 12Gb/s SAS performance when used on a DL580 Gen8 with 12Gb/s devices (SSDs or HDDs)
• 6Gb/s SAS technology delivers high performance and data bandwidth and contains full compatibility with 6Gb/s SATA technology.
• PCI Express Gen3 x8 link width delivers high performance and data bandwidth up to 8 GT/s theoretical maximum bandwidth
• 2 or 4 GiBytes Flash Backed Write Cache (FBWC) provides read ahead caching and write back caching with indefinite write cache data retention in the case of unexpected power outage
• Standard on the P430 are RAID 6 ADG, RAID 60 ADG, RAID 1 ADM, Capacity Expansion, mirror split, recombine, and rollback in Online Mode, Drive Erase, Performance Optimization-Degraded Reads and Read Coalescing, Move/Delete any individual LUNS and Online Split Mirror.
• Capable of supporting both legacy and UEFI boot operation on a DL580 Gen8 server
• The HPE SSD Smart Path feature included in the Smart Array software stack improves SSD read for all RAID levels and RAID 0 write operations by optimizing the path to each SSD attached to the controller
• The HPE SmartCache feature (HPE Smart Cache license is required on P430) is a controller-based read caching solution in a DAS environment that caches the most frequently accessed data ("hot" data) onto lower latency SSDs to dynamically accelerate application workloads.
• The HPE Secure Encryption, available as an option, is a Smart Array controller-based data encryption solution for ProLiant Gen 8 servers that protect sensitive, mission critical data.
• Mix-and-match SAS and SATA hard drives lets you deploy drive technology as needed to fit your computing environment.
• Software consistency on most current shipping Smart Array products: HPE Smart Storage Administrator, HPE Systems Insight Manager (SIM), and HPE Intelligent Provisioning. The HPE Smart Storage Administrator configures and manages a host of Smart Array Controllers and other storage devices using a single interface. It replaces the HPE Array Configuration Utility (ACU) with an updated design and configuration enhancements.
• Low-profile PCI Express form factor - ships with a full size and a low profile bracket for deployment flexibility based on slot availability.

Management Features

• Online array expansion
• Online capacity expansion
• Online logical drive extension
• Online RAID level migration
• Online stripe size migration
• Online mirror split, recombine and rollback
• Online and high performance offline Rapid Parity Initialization (RPI)
• Unlimited global online spare assignment
• User selectable expand and rebuild priority
• User selectable RAID level and stripe size
• User selectable read and write cache sizes
• Supports Predictive Spare Activation

Ports

• Eight (8) SAS physical links on 1 internal x8 Mini-SAS double-wide connector

Performance

• 12Gb/s SAS (1200 MB/s theoretical bandwidth per physical lane) on a DL580 Gen8
• 6Gb/s SAS (600MB/s theoretical bandwidth per physical lane)
• x8 6Gb/s SAS physical lane (compatible with 6Gb/s SATA )
• 2 GiBytes 72-bit wide DDR3-1600MHz Flash Back Write Cache provides up to 12.8GB/s maximum cache bandwidth or 4 GiBytes 72-bit wide DDR3-1866 Flash Back Write Cache provides up to 14.9GB/s maximum cache bandwidth
• PCI Express Gen3 x8 link width
• Read ahead caching
• Write-back caching

Availability

Provides increased server uptime by providing advanced storage functionality:

• Online RAID level migration between any RAID levels
• Online stripe size migration
• Online capacity expansion
• Online logical drive extension
• Online active drive replacement
• Online drive firmware upgrade
• Unlimited global online spare
• Pre-Failure Warranty

Fault Prevention

The following features offer detection of possible failures before they occur, allowing preventive action to be taken:

• S.M.A.R.T.: Self Monitoring Analysis and Reporting Technology first developed at HPE detects possible hard disk failure before it occurs, allowing replacement of the hard drive before a real failure occurs.
• Drive Parameter Tracking monitors drive operational parameters, predicting failure and notifying the administrator.
• Dynamic Sector Repairing continually performs background surface scans on the hard disk drives during inactive periods and automatically remaps bad sectors, ensuring data integrity.
• Smart Array Cache Tracking monitors integrity of controller cache, allowing pre-failure preventative maintenance.

Fault Tolerance

Keeps data available and server running while a failed drive is being replaced; several fault tolerance configurations are supported including:

• RAID 6 (Advanced Data Guarding): Supported with a minimum of 4 drives. This allocates two sets of parity data across drives. This level of fault tolerance can withstand a double drive failure without downtime or data loss.
• RAID 60: Supported with a minimum of 8 drives. This volume is composed of two or more RAID 6 sub-volumes (parity groups) where data is striped across each parity group as if it were a single physical drive. Each RAID 6 parity group can sustain up to two drive failures without incurring data loss.
• RAID 5 (Distributed Data Guarding): Supported with a minimum of 3 drives. This allocates one set of parity data across drives. This level of fault tolerance can withstand a single drive failure without downtime or data loss.
• RAID 50: Supported with a minimum of 6 drives. This volume is composed of two or more RAID 5 sub-volumes (parity groups) where data is striped across each parity group as if it were a single physical drive. Each RAID 5 parity group can sustain a single drive failure without incurring data loss.
• RAID 1 & 10 (Drive Mirroring): Supported with a minimum of 2 drives. This allocates half of the drive array to the data and the other half to the mirrored data, providing two copies of the data.
• RAID 1 ADM & 10 ADM (Advanced Data Mirroring): Supported with a minimum of 3 drives. RAID 1 ADM creates redundant copies of the data using 3 drives. RAID 10 ADM stripes data across two or more sets of RAID 1 ADM volumes. This level of fault tolerance can withstand a double drive failure within a RAID 1 ADM volume without downtime or data loss.

Fault Recovery

Minimizes downtime, reconstructs data, and facilitates a quick recovery from drive failure

• Recovery ROM: This feature protects the user from a firmware image corruption by storing a redundant copy of the firmware image. If the active firmware image becomes corrupt, the controller will use the redundant firmware image and continue operating.
• On-Line Spares: There is no limit to the number of spare drives that can be installed prior to drive failure. If a failure occurs, recovery begins with an On-Line Spare and data is reconstructed automatically.
• DRAM ECC detects and corrects data bit errors

Ease of Use

Consistency and upgradeability on most current shipping Smart Array products make them unique in the industry:

• GUI based configuration, management and diagnostic software tools with the HPE Smart Storage Administrator
• Common data format between generations of products
• Data migration between servers and external Modular Smart Array enclosures and Disk Enclosures

HPE SSD Smart Path

The HPE SSD Smart Path feature included in the Smart Array software stack improves Solid State Disk (SSD) read performance. With up to 4x better SSD read performance, HPE SSD Smart Path chooses the optimum path to the SSD and accelerates reads for all RAID levels and RAID 0 writes. HPE SSD Smart Path requires updated firmware, drivers, and configuration utility available at: http://www.hp.com/go/hpssa. HPE SSD Smart Path is ideal for read intensive workloads and is included as a base feature on HPE Smart Array P-series controllers. The following operating systems are supported by the HPE SSD Smart Path feature:" Microsoft Windows Server 2008

• Microsoft Windows Server 2008 R2
• Microsoft Windows Server 2012
• Red Hat Enterprise Linux 6.1, 6.2, 6.3, 6.4, and 6.5
• SUSE Linux Enterprise Server 11 (SP1, SP2, SPA)
• VMware ESXi 5.0 U3
• VMware vSphere 5.1 U2 and vSphere 5.5

HPE SmartCache

The HPE SmartCache feature is a controller-based read caching solution in a DAS environment that caches the most frequently accessed data ("hot" data) onto lower latency SSDs to dynamically accelerate application workloads. The HPE SmartCache architecture is flexible and supports any HPE ProLiant Gen8 supported HDD for bulk storage and any HPE ProLiant Gen8 supported SSD as an accelerator.

HPE SmartCache is deployed and managed using the HPE SmartStorage Administrator (HPE SSA).

The basic HPE SmartCache architecture is comprised of the following three elements:

• Bulk storage: The first element is the bulk storage device, which is any supported HDD attached to the HPE Smart Array controller.
• Accelerator: The second element, the accelerator, is a faster/lower latency SSD device that caches data.
• Metadata: The final element is metadata, information held in the FBWC that maps the location of information residing on the accelerator and bulk storage devices.

For more information please visit: http://www.hp.com/go/smartcache

HPE Secure Encryption

HPE Secure Encryption is a Smart Array controller-based data encryption solution for ProLiant Gen 8 servers that protects sensitive, mission critical data. This is an enterprise-class encryption solution for data at rest on any bulk storage attached (with the exception of tape or external arrays such as P2000 and MSA 2040) to the supported HPE Smart Array Px3x family of controllers including data on the cache memory of the controller.

The solution is available for both local and remote key management mode deployments. Local Key Management Mode is focused on single server deployment where there is one Master key per controller that is managed by the user. All volumes still have their own unique key(s) for data encryption. Remote Key Management Mode is for enterprise wide deployments and requires HPE Integrated Lights Out (iLO) Advanced or Scale Out editions v 1.40 or later and HPE Enterprise Secure Key Manager (ESKM) 3.1 or any later release. The HPE ESKM manages all the encryption deployments from just a few servers to thousands of servers and 2 million keys per HPE ESKM 3.1 cluster.

For more information please visit http://www.hp.com/go/hpsecureencryption

Warranty

The warranty for this device is 3-years parts only.

Pre-Failure Warranty: Drives attached to the Smart Array Controller and monitored under Insight Manager are supported by a Pre-Failure (replacement) Warranty. For complete details, consult the HPE Support Center or refer to your HPE Server Documentation.

Warranty Upgrade Options

• Response - Upgrade on-site response from next business day to same day 4 hours
• Coverage - Extend hours of coverage from 9 hours x 5 days to 24 hours x 7 days
• Duration - Select duration of coverage for a period of 1, 3, or 5 years
• Warranty upgrade options can come in the form of Care Packs, which are sold at the HPE System level to which this product attaches.

Server Support

For up to date compatibility, please see the following URL for complete Smart Array Controller compatibility and support information: http://www.hp.com/go/smartarray

Operating Systems

Microsoft Windows Server 2008 R2

Microsoft Windows Server 2012

Red Hat Enterprise Linux 5 (x64 & x86)

Red Hat Enterprise Linux 6 (x64 & x86)

SUSE Linux Enterprise Server 11 (x64 & x86)

VMware ESXi 5.0 U2

VMware ESXi 5.1 U1

VMware vSphere 5.5

NOTE: For more information on HPE's Certified and Supported ProLiant Servers for OS and Virtualization Software and the latest listing of software drivers available for your server and Smart Array RAID controller, please visit our Support Matrix at: http://www8.hp.com/us/en/products/servers/management/operating-environments/os-support-matrix.html

Software Suite

Most current shipping Smart Array products share a common set of configuration, management and diagnostic tools, including HPE Smart Storage Administrator and HPE Systems Insight Manager. This software consistency of tools reduces the cost of training for each successive generation of product and takes much of the guesswork out of troubleshooting field problems. These tools lower the total cost of ownership by reducing training and technical expertise necessary to install and maintain HPE server storage.

HPE Systems Insight Manager

• Powerful server and server options/storage manager tool
• Monitors over 1200 system wide parameters
• Configuration/Diagnostic Utilities

HPE Smart Storage Administrator

• Comprehensive management for HPE Smart Storage products
• Simplified and intuitive interface and functionality
• Advanced scripting and diagnostic features

For more information please visit: http://www.hp.com/go/hpssa
