HPE ProLiant s6500 Chassis: технические характеристики и документация

HPE ProLiant s6500 Chassis

The HPE ProLiant s6500 chassis can accommodate up to eight half-width or four full width servers gives you the ability to mix and match server nodes, and also allows for single node serviceability (SNS)-making it an extremely flexible chassis. This, in other words, means that you can add or remove compute capacity based on your business needs. The highly efficient multi-node chassis with shared power and cooling components, including energy efficient fans and optional hot-plug redundant PSU helps reduce power consumption when compared to previous generation servers.

Front View:

Back View:

1.

Server Bay 1

1.

Fan 8

2.

Server Bay 2

2.

Fan 7

3.

Server Bay 3

3.

SL-APM interface

4.

Server Bay 4

4.

Power supply 4

5.

Server Bay 5

5.

Fan 4

6.

Server Bay 6

6.

Fan 3

7.

Server Bay 7

7.

Fan 1

8.

Server Bay 8

8.

Fan 2

9.

Power Supply 1

10.

Power Supply 2

11.

Power Supply 3

12.

Fan 5

13.

Fan 6

What's New

• Updating supported options

System Fans

Non-redundant model
Redundant model
NOTE: all 8 fan bays must be populated with either redundant or non-redundant fans
NOTE: mixing and matching of fans is not supported

Form Factor

HPE ProLiant s6500 Chassis - 4U

Warranty

This product is covered by a global limited warranty and supported by HPE Services and a worldwide network of Hewlett Packard Enterprise Authorized Channel Partners. Hardware diagnostic support and repair is available for one year from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HPE Pointnext operational services or customized service agreements. Hard drives have either a one year or three year warranty.
NOTE: Server Warranty includes 1 year Parts, 1 year Labor, 1-year on-site support with next business day response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have HPE replace Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is available at: http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html.

Factory Express Portfolio for Servers and Storage

HPE Factory Express offers configuration, customization, integration and deployment services for Hewlett Packard Enterprise servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.

Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging, and custom packaging. Hewlett Packard Enterprise products supported through Factory Express include a wide array of servers and storage: HPE Integrity, HPE ProLiant, HPE ProLiant Server Blades, HPE BladeSystem, HPE 9000 servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network switches.

For more information on Factory Express services for your specific server model please contact your sales representative or go to: http://www.hp.com/go/factory-express.

Service and Support

The support services for s6500 chassis  includes support for trays SL390s, SL230s, SL250s, SL270s - No separate  support care pack are required for the trays.

HPE Technology Services for Industry Standard Servers

HPE Technology Services delivers confidence, reduces risk and helps customers realize agility and stability. Connect to HPE to help prevent problems and solve issues faster. Our support technology lets you to tap into the knowledge of millions of devices and thousands of experts to stay informed and in control, anywhere, any time.

Protect your business beyond warranty with HPE Pointnext operational services

HPE Pointnext operational services enable you to order the right service level, length of coverage and response time as you purchase your new server, giving you full entitlement for the term you select.

Optimized Care

Supports maintaining servers at optimum performance availability

HPE Proactive Care with 24x7 coverage, three year Care Pack Service

HPE Proactive Care helps prevent problems and stabilize IT by utilizing secure, real-time, predictive analytics and proactive consultations when your products are connected to HPE.  This Care Pack Service combines three years’ proactive reporting and advice with our 24x7 coverage and enhanced escalation management, four hour hardware response time and two hour call back for software questions on leading industry standard software running on your HPE ProLiant server. http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA3-8855ENW.pdf

Standard Care

Package that maintains high level of server availability

Foundation Care 24x7, three-year Care Pack Service

HPE Foundation Care 24x7 connects you to Hewlett Packard Enterprise 24 hours a day, seven days a week for assistance on resolving issues. Hardware onsite response within four hours  if needed; collaborative software included in this Care Pack service provides troubleshooting assistance on industry leading software running on your HPE server.  Simplify your support experience and make HPE your first call for hardware or software questions.

https://www.hpe.com/h20195/V2/GetDocument.aspx?docname=4AA4-8876ENW&cc=us&lc=en

Related Services

HPE Datacenter Care service

HPE Datacenter Care helps you improve IT stability and security, increase the value of IT, and enable agility and innovation.  It is a structured framework of repeatable, tested, and globally available services “building blocks.” You can deploy, operate, and evolve your datacenter wherever you are on your IT journey. With HPE Datacenter Care, you benefit from a personalized relationship with HPE via a single point of accountability for HPE and others’ products.  For more information, visit http://www.hp.com/services/datacentercare

HPE ProLiant Server Hardware Installation
Provides for the basic hardware installation of Hewlett Packard Enterprise branded servers, storage devices and networking options to assist you in bringing your new hardware into operation in a timely and professional manner.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf

Factory Express for Servers and storage

HPE Factory Express offers configuration, customization, integration and deployment services for Hewlett Packard Enterprise servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed. For more information on Factory Express services for your specific server model please contact your sales representative or go to: http://www.hp.com/go/factory-express.

Data Privacy Services

Protect your data through better media management.  HPE Data privacy services help manage and protect sensitive data to reduce the risk of unauthorized access to private information and help meet compliance requirements.  Our retention services allow you to keep drives and other devices upon failure, our removal services provide convenient data sanitization and our recovery services allow you to safely retire IT assets and capture any remaining value from the hardware. http://www.hp.com/services/dataprivacy

Additional HPE Pointnext operational services can be found at: http://www.hp.com/go/cpc

Get connected to HPE to improve your support experience

Prevent problems with innovative, automated monitoring tools and proactive services. Combining Proactive Care Services with our remote support technology  such as Insight Online  provides you with expert advice and personalized, cloud-based automated IT support, helping to prevent unplanned down time and solve problems quickly. For more information, visit: http://www.hp.com/go/proactiveinsightexperience

Parts and Materials

Hewlett Packard Enterprise will provide HPE-supported replacement parts and materials necessary to maintain the covered hardware product in operating condition, including parts and materials for available and recommended engineering improvements.

Parts and components that have reached their maximum supported lifetime and/or the maximum usage limitations as set forth in the manufacturer's operating manual, product quick-specs, or the technical product data sheet will not be provided, repaired, or replaced as part of these services.

The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by Hewlett Packard Enterprise due to malfunction.

For more information

To learn more on HPE ProLiant servers and HPE BladeSystem servers, please contact your Hewlett Packard Enterprise sales representative or Hewlett Packard Enterprise Authorized Channel Partner. Or visit: http://www.hp.com/services/proliant

s6500 SL Server Support

Server Nodes

HP ProLiant SL270s Gen8 SE 4U Left Tray Configure-to-order Server

739055-B21

HP ProLiant SL270s Gen8 SE 4U Right Tray Configure-to-order Server

739056-B21

Pre-configured Models
HPE ProLiant s6500 chassis

HP ProLiant s6500 3/1200 Redundant Fan Chassis
629236-B21

Power Supply

(3) 1200W (94% efficient) Platinum Plus Hot Plug Power Supplies

Fans

(8) hot plug redundant fans

Form Factor

4U chassis

Tray blank

1 right and 1 left tray blank

Power supply blanks

1 power supply blank

HP ProLiant s6500 2/1200 Non Redundant Fan Chassis
629235-B21

Power Supply

(2) 1200W (94% efficient) Platinum Plus Hot Plug Power Supplies

Fans

(8) hot plug non-redundant fans

Form Factor

4U chassis

Tray blank

1 right and 1 left tray blank

Power supply blanks

2 power supply blank

S6500 tray mixing support plan
NOTE: s6500 is a 4U chassis and has a left and a right side when using ½ width trays.
NOTE: The picture below show how each half of the chassis can be configured.
NOTE: A full width tray uses the entire width of the chassis
NOTE: Mixing and matching of half width trays is supported.
NOTE: Mixing and Matching of Full width trays is supported
NOTE: Mixing and matching of Full and half width trays is NOT supported.
NOTE: 2U half width tray is NOT supported in middle 2 bays.

NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, Hewlett Packard Enterprise recommends the use of an Hewlett Packard Enterprise approved configurator. Contact your local sales representative for information on configurable product offerings and requirements.
NOTE: FIO indicates that this option is only available as a factory installable option.

Step 1: Base Configuration (choose one from each list unless otherwise noted)

HPE Chassis

HPE ProLiant s6500 w/o Fans 4U Configure-to-order Chassis
NOTE:NOTE: You must choose Power Supplies and fans as the chassis does not include them.

614167-B21

HPE Chassis Fans

HP s6500 Non Redundant Fan Kit
NOTE: This kit includes only 1 fan
NOTE: This selection must be ordered in quantities of 8.

617858-B21

HP s6500 Redundant Fan Kit
NOTE: This kit includes only 1 fan
NOTE: This selection must be ordered in quantities of 8.

617856-B21

HPE Tray Blanks

HP s6500 Half Width Node Left Blank Kit
NOTE: Node blank is needed when not completely filling s6500 chassis and when servicing a node.

688928-B21

HP s6500 Half Width Node Right Blank Kit
NOTE: Node blank is needed when not completely filling s6500 chassis and when servicing a node.

688930-B21

HPE Power Supplies

NOTE: Mixing of power supplies in the same chassis is not supported. All power supplies inside a server must be exactly the same model. Mixing Gold, Platinum, and Platinum Plus certified power supplies is not supported.
NOTE: Prior to making a power supply selection it is highly recommended that the HPE Power Advisor is run to determine the right size power supply for your server configuration. The HPE Power Advisor is located at: http://www.hp.com/go/hppoweradvisor.

NOTE: Choose correct power supply from list below depending on generation of server.
NOTE: The s6500 chassis is limited to 4800W AC or 4320W DC after losses. This does not change with the 1500W Power Supplies. 1500W Power Supplies provide higher processor wattage support and more power in a redundant or N+N configuration.

HPE Common Slot Platinum Plus Power Supply Kits
NOTE: These power supplies support Gen8 servers.

HPE 750W Common Slot Platinum Plus Hot Plug Power Supply Kit

656363-B21

HPE 1200W Common Slot Platinum Plus Hot Plug Power Supply Kit

656364-B21

HPE 1500W Common Slot Platinum Plus Power Supply Kit

684532-B21

HPE Common Slot Platinum Power Supplies
NOTE: This Power Supply supports G6 and G7 servers.

HPE 1200W Common Slot Platinum Hot Plug Power Supply Kit

578322-B21

HPE Common Slot Gold Power Supplies
NOTE: This Power Supply supports G6 and G7 servers.

HPE 750W Common Slot Gold Hot Plug Power Supply Kit

512327-B21

HPE Common Slot 277VAC Power Supplies
NOTE: 94% efficiency.

HPE Common Slot 380VDC Power Supplies
NOTE: 94% efficiency.

NOTE: Power Specification and Technical Content for supported power supplies can be found at: https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04111541

NOTE: The following Power Supplies can only be implemented with servers containing Ivy Bridge processors. These Power Supplies will not be compatible with any servers with Sandy Bridge Processors.

HPE 750W Common Slot Platinum Hot Plug Power Supply Kit

739254-B21

HPE 1200W Common Slot Platinum Hot Plug Power Supply Kit

748287-B21

Step 2: Choose Additional Options for Factory Integration
NOTE: For additional options, please refer to the "Additional Options" section below.

HPE Power Supplies

NOTE: Mixing of power supplies in the same chassis is not supported. All power supplies inside a server must be exactly the same model. Mixing Gold, Platinum, and Platinum Plus certified power supplies is not supported.
NOTE: Prior to making a power supply selection it is highly recommended that the HPE Power Advisor is run to determine the right size power supply for your server configuration. The HPE Power Advisor is located at: http://www.hp.com/go/hppoweradvisor.
NOTE: Choose correct power supply from list below depending on generation of server.

HPE Common Slot Platinum Plus Power Supply Kits
NOTE: This Power Supply supports Gen8 servers.

HPE 750W Common Slot Platinum Plus Hot Plug Power Supply Kit

656363-B21

HPE 1200W Common Slot Platinum Plus Hot Plug Power Supply Kit

656364-B21

HPE 1500W Common Slot Platinum Plus Power Supply Kit

684532-B21

HPE Common Slot Platinum Power Supplies
NOTE: This Power Supply supports G6 and G7 servers.

HPE 1200W Common Slot Platinum Hot Plug Power Supply Kit

578322-B21

HPE Common Slot Gold Power Supplies
NOTE: This Power Supply supports G6 and G7 servers.

HPE 750W Common Slot Gold Hot Plug Power Supply Kit

512327-B21

HPE Common Slot 277VAC Power Supplies
NOTE: 94% efficiency.

HPE Common Slot 380VDC Power Supplies
NOTE: 94% efficiency.

NOTE: Power Specification and Technical Content for supported power supplies can be found at: https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04111541

NOTE: The following Power Supplies can only be implemented with servers containing Ivy Bridge processors. These Power Supplies will not be compatible with any servers with Sandy Bridge Processors.

HPE 750W Common Slot Platinum Hot Plug Power Supply Kit

739254-B21

HPE 1200W Common Slot Platinum Hot Plug Power Supply Kit

748287-B21

NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard Enterprise recommends the use of an Hewlett Packard Enterprise approved configurator. Contact your local sales representative for additional information.

HPE SL Advanced Power Manager

The SL Advanced Power Manager is an optional rack level solution for the HPE ProLiant SL4540 and SL4545 which enables server-level DC (or hardware) power on and off and server-level monitoring. In addition, the SL APM will automatically discover SL hardware components which are connected into the SL APM solution.

The SL APM does not replace rack PDUs, but is designed to enable the utilization of basic, low cost, rack PDUs while providing the functionality of 'switched' PDUs which provide hardware power on/off of individual servers by turning off the AC power to the power supplies of a given server. Because the SL servers share power supplies to optimize power efficiency, using 'switched' PDUs to turn off the power supplies in the chassis will result in the loss of all servers in that chassis. The SL APM solves this by allowing server-level hardware power on/off of the DC power to the individual server motherboards.

HPE SL Advanced Power Manager Distribution Module Kit

620002-B21

DC Power Cable Kits

HPE 1.3M 48V DC Power Cable Kit

A5S97A

HPE 2.5M 48V DC Power Cable Kit
NOTE:NOTE: These power cord options are for use with the HPE 750W Common Slot -48VDC Hot Plug Power Supply Kit (636673-B21). A5S98A

A5S98A

HPE T-latch Double Ended WW 18AWG DC 2m Jumper Cord
NOTE:NOTE: This power cord option is for use with the HPE 1200W Common Slot 380VDC Hot Plug Power Supply Kit (684539-B21).

D4J67A

HPE Power Cords

NOTE: HPE ProLiant servers ships with an IEC-IEC power cord used for rack mounting with Power Distribution Units (PDUs).

HPE C13 - C14 WW 250V 10A Gray 0.7m Jumper Cord

A0K03A

HPE C13 - C14 WW 250V 10A Gray 1.37m Jumper Cord

A0K04A

HPE C13 - SEV 1011 CH  250V 10Amp 1.83m Power Cord

AF565A

HPE C13 - DK-2.5A DK  250V 10Amp 1.83m Power Cord

AF566A

HPE C13 - CEE-VII EU 250V 10Amp 1.83m Power Cord

AF568A

HPE C13 - SI-32 IL 250V 10Amp 1.83m Power Cord

AF564A

HPE C13 - NBR-14136 BR 250V 10Amp 1.83m Power Cord

AF591A

HPE C13 - BS-1363A UK/HK/SG 250V 10Amp 1.83m Power Cord

AF570A

HPE C13 - CEI-23-50 IT/CL 250V 10Amp 1.83m Power Cord

AF571A

HPE C13 - C14 WW 250V 10Amp 2.0m Jumper Cord

A0K02A

HPE C13 - IS-1293 IN 250V 10Amp HV 2.5m Power Cord

SG579A

HPE C13 - AS3112-3 AU 250V 10Amp 2.5m Power Cord

AF569A

HPE C13 - SABS-164 ZA 250V 10Amp 2.5m Power Cord

AF567A

HPE C13 - JIS C8303 JP 100V 12Amp 2.0m Power Cord

AF572A

HPE C13 - C14 WW 250V 10A Gray 3.0m Jumper Cord

A0K06A

HPE C13-NEMA 6-15P 10A/250V 3.6m Black Power Cord

A0N33A

HPE C13 - GB-1002 CN 250V 10Amp 1.83m Power Cord

AF557A

HPE C13 - KSC- 8305 KR 250V 10Amp 1.83m Power Cord

AF560A

HPE C13 - CNS-690 TW 110V 13Amp 1.83m Power Cord

AF561A

HPE C13 - Nema 5-15P TH/PH 250V 10Amp 1.83m Power Cord

AF559A

HPE C13 - Nema 5-15P US/CA 110V 10Amp 1.83m Power Cord

AF556A

HPE C13 - IS-1293 IN 240V 6Amp LV 2.0m Power Cord

AF562A

HPE C13 - IRAM -2073 AR 250V 10A 2.5m Power Cord

AF558A

HPE C13 - C14 WW 250V 10Amp Flint Gray 2.0m Jumper Cord

AF573A

HPE Tape Backup

NOTE: For the complete range of tape drives, autoloaders, libraries and media see: http://www.hp.com/go/tape. For hardware and software compatibility of HPE tape backup products see: http://www.hp.com/storage/SPOCK

HPE StoreEver LTO-6 Ultrium 6250 Tape Drive in a 1U Rack Mount Kit

C0L99A

HPE StoreEver 1/8 G2 LTO-6 Ultrium 6250 Fibre Channel Tape Autoloader

C0H19A

HPE Tape Storage Systems

HPE StoreEver MSL6480

HPE StoreEver MSL6480 Scalable Base Module

QU625A

NOTE: Please see the QuickSpecs for Technical Specifications and additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04111416 (Worldwide)

HPE Disk Storage Systems

Disk Enclosures

NOTE: Please see the QuickSpecs for Technical Specifications and additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04111697 (Worldwide)

HPE Uninterruptible Power Systems

HPE Rack-mountable UPS

HPE R1500 G3 Uninterruptible Power Supply (UPS)

NOTE: Please see the QuickSpecs for additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04154376 (Worldwide)

HPE R/T3000 G2 Uninterruptible Power System (UPS)

NOTE: Please see the QuickSpecs for additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04154342 (Worldwide)

R5000 Uninterruptible Power System (UPS)

HPE R5000 3U IEC309-32A High Voltage INTL Uninterruptible Power System

AF461A

HPE R5000 3U L630 High Voltage NA/JP Uninterruptible Power System

AF460A

NOTE: Please see the QuickSpecs for additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04154372(Worldwide)

R7000 Uninterruptible Power System (UPS)

HPE R7000 4U 50A High Voltage NA/JP Uninterruptible Power System

AF462A

HPE R7000 4U IEC-32A High Voltage INTL Uninterruptible Power System

AF463A

NOTE: Please see the QuickSpecs for additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04123199 (Worldwide)

NOTE: For additional information on sizing your HPE UPS, please reference: http://www.upssizer.com

NOTE: Please see the UPS and PDU cable matrix's on the HPE Power Protection and Management page. Under Power Cords, click on the "HPE Power Cord Matrix" link. That link will list cable descriptions, requirements, and specifications for UPS and PDU units. Please see the following link: http://www.hp.com/products/powercords.
NOTE: For additional information on HPE Uninterruptible Power Systems please go to: http://www.hp.com/servers/rackups.

HPE Basic Power Distribution Units
(bPDU)

HPE Basic Power Distribution Unit: 1U/0U Version

HPE Basic 1.9kVA/L5-20P 16A/120V Outlets (12) 5-20R/Horizontal NA/JP PDU

H5M54A

HPE Basic 3.6kVA/60320 C20 Detachable 16A/230V Outlets (12) C13/Horizontal WW PDU

H5M56A

HPE Basic Power Distribution Unit: Half Height Version

HPE Basic 2.8kVA/L5-30P 24A/120V Outlets (18) 5-20R/Vertical NA/JP PDU

H5M55A

HPE Basic 4.9kVA/60320 C20 Detachable 16A/230V Outlets (20) C13/Vertical WW PDU

H5M57A

HPE Basic 4.9kVA/L6-30P 24A/208V Outlets (20) C13/Vertical NA/JP PDU

H5M58A

HPE Basic 7.3kVA/60309 5-wire 32A/230V Outlets (20) C13/Vertical INTL PDU

H5M68A

HPE Basic 3Ph 8.6kVA/L15-30P 24A/208V Outlets (18) C13/Vertical NA/JP PDU

H5M61A

HPE Basic Power Distribution Unit: Mid Height Version

HPE Basic 4.9kVA/L6-30P 24A/208V Outlets (24) C13 (6) C19/Vertical NA/JP PDU

H5M59A

HPE Basic 7.3kVA/60309 3-wire 32A/230V Outlets (24) C13 (6) C19/Vertical INTL PDU

H5M70A

HPE Basic 8.3kVA/CS8265C 40A/208V Outlets (30) C13 (6) C19/Vertical NA PDU

H5M60A

HPE Basic 11kVA/60309 63A 3-wire 48A/230V Outlets (30) C13 (6) C19/Vertical INTL PDU

H5M71A

HPE Basic 9.2kVA/50A Terminal Block 40A/230V Outlets (30) C13 (6) C19/Vertical WW PDU

H5M75A

HPE Basic 3Ph 5.7kVA/ L21-20P 16A/120-208V Outlets (24) C13 (3) 5-20R/Vertical NA/JP PDU

H5M63A

HPE Basic 3Ph 8.6kVA/L21-30P 24A/120-208V Outlets (24) C13 (3) C19 (3) 5-20R/Vertical NA/JP PDU

H5M64A

HPE Basic 3Ph 8.6kVA/L15-30P 24A/208V Outlets (24) C13 (6) C19/Vertical NA/JP PDU

H5M62A

HPE Basic 3Ph 11kVA/60309 5-wire 16A/230V Outlets (24) C13 (6) C19/Vertical INTL PDU

H5M72A

HPE Basic Power Distribution Unit: Full Height Version

HPE Basic 3Ph 11kVA/60309 5-wire 16A/230V Outlets (36) C13 (6) C19/Vertical INTL PDU

H5M73A

HPE Basic 3Ph 11kVA/60309 16A/240V Outlets (36) C13 (6) C19/Vertical NA PDU

H5M67A

HPE Basic Power Distribution Unit: 480/277 Volt Version

HPE 800VA - 277V Input / 230V Output NA Rack Mount Transformer

H3X09A

NOTE: Please see the QuickSpecs for Technical Specifications and additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04111392 (Worldwide)

NOTE: Additional HPE Power Distribution Units are available. For a complete list of all HPE PDUs and additional information please visit: http://www.hp.com/go/rackandpower.

HPE Remote Monitoring Power Distribution Units (mPDU)

HPE Remote Monitored Power Distribution Unit: 1U Version

HPE Metered 2.8kVA/L5-30P 24A/120V Outlets (12) 5-20R/Horizontal NA/JP PDU

D9N43A

HPE Metered 3.6kVA/60320 C20 Detachable 16A/230V Outlets (12) C13/Horizontal WW PDU

D9N46A

HPE Metered 4.9kVA/L6-30P 24A/208V Outlets (12) C13/Horizontal NA/JP PDU

D9N44A

HPE Remote Monitored Power Distribution Unit: Half Height Version

HPE Metered 3.6kVA/60320 C20 Detachable 16A/230V Outlets (16) C13/Vertical WW PDU

D9N45A

HPE Remote Monitored Power Distribution Unit: Mid Height Version

HPE Metered 4.9kVA/L6-30P 24A/208V Outlets (20) C13 (4) C19/Vertical NA/JP PDU

D9N47A

HPE Metered 7.3kVA/60309 32A 3-wire/230V Outlets (20) C13 (4) C19/Vertical INTL PDU

D9N48A

HPE Metered 3Ph 8.6kVA/L15-30P 24A/208V Outlets (18) C13 (3) C19/Vertical NA/JP PDU

D9N51A

HPE Metered 3Ph 8.6kVA/L21-30P 24A/120-208V Outlets (18) C13 (3) C19 (3) 5-20R/Vertical NA/JP PDU

D9N53A

HPE Metered 3Ph 11kVA/60309 5-wire 16A/230V Outlets (18) C13 (3) C19/Vertical INTL PDU

D9N55A

HPE Remote Monitored Power Distribution Unit: Full Height Version

HPE Metered 8.3kVA/CS8265C 40A/208V Outlets (30) C13 (3) C19/Vertical NA PDU

D9N49A

HPE Metered 7.3kVA/60309 32A 3-wire/230V Outlet (32) C13 (4) C19/Vertical INTL PDU

D9N50A

HPE Metered 3Ph 11kVA/60309 5-wire 16A/230V Outlets (30) C13 (3) C19/Vertical INTL PDU

D9N57A

HPE Metered 3Ph 14.4kVA/CS8365C 40A/208V Outlets (12) C13 (12) C19/Vertical NA/JP PDU

D9N58A

HPE Metered 3Ph 16.6kVA/60309 32A-30A 5-wire 24A/230V Outlets (30) C13 (3) C19/Vertical NA/JP PDU

D9N61A

HPE Metered 3Ph 17.3kVA/60309 60A 4-wire 48A/208V Outlets (24) C13 (3) C19/Vertical NA/JP PDU

D9N54A

HPE Metered 3Ph 17.3kVA/60309 60A 4-wire 48A/208V Outlets (12) C13 (12) C19/Vertical NA/JP PDU

D9N59A

HPE Metered 3Ph 22kVA/60309 5-wire 32A/230V Outlets (12) C13 (12) C19/Vertical INTL PDU

D9N60A

HPE Metered 3Ph 22kVA/60309 5-wire 32A/230V Outlet (30) C13 (3) C19/Vertical INTL PDU

D9N56A

HPE Metered 3Ph 16.6kVA/60309 32A-30A 5-wire 24A/230V Outlets (12) C13 (12) C19/Vertical NA/JP PDU

D9N62A

HPE Metered 3Ph 19.9kVA/L22-30P 24A/277V Outlets (30) RF-203P-HP/Vertical NA PDU

D9N63A

HPE Environmental Sensor for Remote Monitored PDUs

HP Environmental Sensor for Remote Monitored and Managed PDUs

E2D53A

NOTE: Please see the QuickSpecs for additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04229509 (Worldwide)

HPE Intelligent Power Distribution Units (iPDU)

iPDU Core Units

HPE Intelligent Modular 4.9kVA/L6-30P 24A/208V Outlets (6) C19/Horizontal NA/JP PDU

AF520A

HPE Intelligent Modular 8.3kVA/CS8265C 40A/208V Outlets (6) C19/Horizontal NA/JP PDU

AF521A

HPE Intelligent Modular 3Ph 8.6kVA/L15-30P 24A/208V Outlets (6) C19/Horizontal NA/JP PDU

AF522A

HPE Intelligent Modular 3Ph 14.4kVA/CS8365C 40A/208V Outlets (6) C19/Horizontal NA/JP PDU

AF533A

HPE Intelligent Modular 3Ph 17.3kVA/60309 60A 4-wire 48A/208V (6) C19/Horizontal NA/JP PDU

AF523A

HPE Intelligent Modular 7.3kVA/60309 3-wire 32A/230V Outlets (6) C19/Horizontal INTL PDU

AF525A

HPE Intelligent Modular 3Ph 11kVA/60309 5-wire 16A/230V Outlets (6) C19/Horizontal INTL PDU

AF526A

HPE Intelligent Modular 3Ph 22kVA/60309 5-wire 32A/230V Outlets (6) C19/Horizontal INTL PDU

AF527A

HPE Intelligent Modular 3Ph 17.3kVA/IEC 60309 60A 4-wire 48A/208V (12) C19/Horizontal NA/JP PDU

AF535A

HPE Intelligent Modular 3Ph 22kVA/60309 5-wire 32A/230V Outlets (12) C19/Horizontal INTL PDU

AF538A

iPDU Kits with Standard Extension Bars

HPE Intelligent Modular 4.9kVA/L6-30P 24A/208V Outlets (20) C13 (6) C19/Horizontal NA/JP PDU

AF531A

HPE Intelligent Modular 3Ph 8.6kVA/L15-30P 24A/208V Outlets (20) C13 (6) C19/Horizontal NA/JP PDU

AF532A

HPE Intelligent Modular 7.3kVA/60309 3-wire 32A/230V Outlets (6) C19/Horizontal INTL PDU Kit

AF534A

iPDU Extension Bars

HPE 5xC13 Intelligent PDU Extension Bar G2 Kit

AF547A

HPE 5xC13 Outlets Power and UID LEDs Pair Standard Extension Bar

AF528A

NOTE: Please see the QuickSpecs for Technical Specifications and additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04123329 (Worldwide)
NOTE: Additional HPE Power Distribution Units are available. For a complete list of all HPE PDUs and additional information please visit: http://www.hp.com/go/rackandpower.

HPE Rail Kits

HPE s6500 4U Chassis

598109-B21

HPE Rack Series

HPE Intelligent Series Rack

HP 36U 600mm x 1200mm Enterprise Pallet Rack

BW899A

HP 36U 600mm x 1200mm Enterprise Shock Rack

BW900A

HP 42U 600mm x 1200mm Enterprise Pallet Rack

BW907A

HP 42U 600mm x 1200mm Enterprise Shock Rack

BW908A

HP 47U 600mm x 1200mm Enterprise Pallet Rack

BW913A

HP 47U 600mm x 1200mm Enterprise Shock Rack

BW914A

NOTE: Please see the QuickSpecs for Technical Specifications such as height, width, depth, weight, and color:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04123237 (Worldwide)
NOTE: For additional information regarding Rack Cabinets, please see the following URL: http://www.hp.com/go/rackandpower.

HPE Rack Options

HPE TFT7600 G2 KVM Console Rackmount Keyboard Monitor

NOTE: Please see the QuickSpecs for Technical Specifications and additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04154398 (Worldwide)

HPE Server Console Switches

NOTE: Please see the QuickSpecs for Technical Specifications and additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04123433 (Worldwide)

HPE Server Console Switch G2 with Virtual Media & CAC

HP 0x2x16 KVM Server Console Switch G2 with Virtual Media CAC Software

AF618A

HP 0x2x32 KVM Server Console Switch G2 with Virtual Media CAC Software

AF619A

KVM USB Cnsl Itfc Adapter 1PK ALL

336047-B21

NOTE: Please see the QuickSpecs for Technical Specifications and additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04168373 (Worldwide)

HPE IP Console Switch G2 with Virtual Media & CAC

HP 1x4 USB/PS2 KVM Console Switch

AF611A

HP 1x1Ex8 KVM IP Console Switch G2 with Virtual Media CAC Software

AF620A

HP 2x1Ex16 KVM IP Console Switch G2 with Virtual Media CAC Software

AF621A

HP 4x1Ex32 KVM IP Console Switch G2 with Virtual Media CAC Software

AF622A

NOTE: Please see the QuickSpecs for Technical Specifications and additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04168374
(Worldwide)

HPE Pointnext operational services

Proactive Care

NOTE: Collaborative Support plus Proactive services delivered by the on shore/near shore Advanced Solution Center (ASC) and backed by the global delivery organization, end-to-end case ownership from a Technical Solution Specialists and

Technical Account Manager who remotely delivers firmware/software revision management, proactive scans and incident trend reports. Recommended for customers running a virtualized infrastructure and/or customers who desire an enhanced call support experience.

Proactive Care Personalized Support Environmental Option

NOTE: to add an onsite Account Support Manager (ASM) to Proactive Care. ASM is an assigned resource who delivers support planning and brings technical expertise and best practices advice for the customer's environment.

HPE 3 year Proactive Care Next business day ProLiant s6500 Service

U3C66E

HPE 3 year Proactive Care 24x7 ProLiant s6500 Service

U3C72E

HPE 3 year Proactive Care 24x7 with DMR ProLiant s6500 Service

U3C75E

HPE 3 year Proactive Care 24x7 with CDMR s6500 Service

U9F76E

Foundation Care
NOTE: HPE Foundation Care 24x7 connects you to Hewlett Packard Enterprise 24 hours a day, seven days a week for assistance on resolving issues. Hardware onsite response within four hours if needed; collaborative software included in this Care Pack service provides troubleshooting assistance on industry leading software running on your HPE server. Simplify your support experience and make HPE your first call for hardware or software questions.

HPE 3 year Foundation Care 24x7 ProLiant s6500 Service

U2FN6E

HPE 3 year Foundation Care 24x7 wDMR ProLiant s6500 Service

U2FN7E

HPE 3 year Foundation Care 24x7 wCDMR ProLiant s6500 Service

U2FN8E

Installation Services
NOTE: Reduce the time required to get your system up and running and help minimize disruptions to your business.

HPE Install ProLiant s6500 Service

UR422E

HPE Startup ProLiant s6500 Service

UR423E

HPE Installation Non Standard Hours ProLiant s6500 Service

UR424E

NOTE: For more information, customer/resellers can contact: http://www.hp.com/services/carepack

System Unit

Chassis Dimensions (H x W x D)

6.96 x 17.638 x 35.236in (17.68 x 44.8 x 89.55cm)

Weight
(approximate)

Maximum
(all hard drives, power supplies, and processors installed)

220lb (99.8kg)

Input Requirements
(per power supply)

Rated Line Voltage

90 to 140 VAC
180 to 264 VAC

Rated Input Current

7.31A at 115VAC
3.6A at 230VAC

Rated Input Frequency

47 to 63 Hz

Rated Input Power

855W (at 100 VAC),
840.72W (at 200 VAC)

Power Specifications

To review system power requirements, use the HPE Power Advisor which is available via download or online at http://www.hp.com/go/hppoweradvisor

Power Supply Output
(per power supply)

Rated Steady-State Power

653.10W (at 100 VAC),
653.08W (at 200 VAC)

System Inlet Temperature

Operating

50° to 95° F (10° to 35° C) at sea level with an altitude derating of 1.8°F per every 1000 ft (1.0°C per every 304.8 m) above sea level to a maximum of 10,000 ft (3048 m), no direct sustained sunlight. Maximum rate of change is 18°F/hr (10°C/hr). The upper limit may be limited by the type and number of options installed.
System performance may be reduced if operating with a fan fault or above 86°F (30°C).

Non-operating

-22° to 140° F (-30° to 60° C)
Maximum rate of change is 36°F/hr (20°C/hr).

Relative Humidity
(non-condensing)

Operating

10% to 90% relative humidity (Rh), 82.4°F (28°C) maximum wet bulb temperature, non-condensing.

Non-operating

5% to 95% relative humidity (Rh), 101.7°F (38.7°C) maximum wet bulb temperature, non-condensing.

Altitude

Operating

10,000 ft (3048 m). This value may be limited by the type and number of options installed. Maximum allowable altitude change rate is 1500 ft/min (457 m/min).

Non-operating

30,000 ft (9144 m). Maximum allowable altitude change rate is 1500 ft/min (457 m/min).

Acoustic Noise

Listed are the declared A-Weighted sound power levels (LWAd) and declared average bystander position A-Weighted sound pressure levels (LpAm) when the product is operating in a 23°C ambient environment. Noise emissions were measured in accordance with ISO 7779 (ECMA 74) and declared in accordance with ISO 9296 (ECMA 109).

Idle

LWAd

6.4

LpAm

45dBA

Operating

LWAd

6.7

LpAm

51dBA

Emissions Classification
(EMC)

FCC Rating

Class A

Normative Standards

CISPR 22; EN55022; EN55024; FCC CFR 47, Pt 15; ICES-003; CNS13438; GB9254; K22;K24; EN 61000-3-2; EN 61000-3-3; EN 60950-1; IEC 60950-1

NOTE: Product conformance to cited product specifications is based on sample (type) testing, evaluation, or assessment. This product or family of products is eligible to bear the appropriate compliance logos and statements.

Environment-friendly Products and Approach

End-of-life Management and Recycling

Hewlett Packard Enterprise offers end-of-life Hewlett Packard Enterprise product return, trade-in, and recycling programs in many geographic areas. For trade-in information, please go to: http://www.hp.com/go/green. To recycle your product, please go to: http://www.hp.com/go/green or contact your nearest Hewlett Packard Enterprise sales office. Products returned to Hewlett Packard Enterprise will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard Enterprise web site at: http://www.hp.com/go/green. These instructions may be used by recyclers and other WEEE treatment facilities as well as Hewlett Packard Enterprise OEM customers who integrate and re-sell Hewlett Packard Enterprise equipment.

Date

Version History

Action

Description of Change

23-Oct-2017

Version 21

Changed

Care Pack naming and Service and Support- Parts and Materials updated.

21-Oct-2016

From Version 19 to 20

Changed

Branding edition.

01-Dec-2014

From Version 18 to 19

Changed

Add new paragraphs to the support section.

01-Nov-2014

From Version 17 to 18

Changed

Updated Service and Support.

27-Jun-2014

From Version 16 to 17

Changed

Power Supplies was revised in Configuration Information.

09-May-2014

From Version 15 to 16

Changed

Power Supplies was revised in Configuration Information.

18-Apr-2014

From Version 14 to 15

Changed

Optimized, Standard, and Basic Care were revised.

13-Dec-2013

From Version 13 to 14

Changed

HPE SL250s Gen8 lvb left and right Tray Node Server were added to Pre-Configured Models

HPE Tape Storage Systems and HPE Disk Storage Systems were added to Additional Options

HPE s6500 Full Width Node Blank Kit was removed from HPE Tray Blanks

HPE 750W Common Slot Platinum Hot Plug Power Supply Kit was removed from HPE Power Supplies

HPE Power Distribution Units was removed from Additional Options

HPE Basic Power Distribution Units, HPE Remote Monitoring Power Distribution Units, and HPE Intelligent Power Distribution Units were revised in Additional Options

10-Sep-2013

From Version 12 to 13

Changed

Server nodes was revised in Pre-configured Models

HPE Power Supplies was revised in Configuration Information - Factory Integrated Models

HPE SL Advanced Manager, DC Power Cable Kits, HPE Power Distribution Units, and HPE Rail Kits were revised in Additional Options

22-Aug-2013

From Version 11 to 12

Added

Additional Options: Added HPE SL Advanced Power Manager and DC Power Cable Kits sections.

05-Jul-2013

From Version 10 to 11

Changed

HPE ProLiant SL390s G7 4U Right and Left Tray Node Servers were added to s6500 SL Server Support

HPE Rail Kits was added to Additional Options

Modular PDUs 1U/0U were removed from HPE Power Distribution Units

15-May-2013

From Version 9 to 10

Added

Additional Options: Added HPE Basic Power Distributions Units section.

Removed

Additional Options: Removed HPE Disk Storage Systems section.

Changed

Pre-Configured Models: Updated s6500 SL Sever Support Server Nodes

Configuration Information-Factory Integrated Models: Updated Step 1 and Step 2 HPE Power Supplies section.

Technical Specifications: Updated System Unit section.

25-Mar-2013

From Version 8 to 9

Removed

Preconfigured Models: Removed 622224-B21, 654393-B21 and 654940-B21 from the section.

Added

Confuguration Information - Factory Integrated Models: Added HPE Common Slot 277VAC Power Supplies Information to the section.

19-Feb-2013

From Version 7 to 8

Changed

Changes made in HPE Pointnext operational services in the Addition Options section.

28-Dec-2012

From Version 6 to 7

Added

Configuration Information: in Step 1 added HPE Chassis Fans

Additional Options: in HPE Tape Backup added HPE Disk Storage Systems

10-Dec-2012

From Version 5 to 6

Added

Added the What's New section

s6500 SL Server Support

Additional Options: HPE Tape Backup, HPE Uninterruptible Power Systems, HPE Power Distribution Units, & HPE intelligent Power Distribution Units (iPUD)

Changed

Changes made to the Models, Configuration Information, Additional Options

16-May-2011

From Version 4 to 5

Changed

Changes made to throughout the QuickSpecs.

16-Dec-2011

From Version 3 to 4

Changed

Changes made in Step 1 of the Configuration Information section.

02-Dec-2011

From Version 1 to 3

Removed

HPE Rack Cable Management Kit, HPE 1200W Common Slot Platinum Plus Hot Plug Power Supply Kit, HPE Power Supplies for s6500 Chassis and 48VDC power supplies were removed from Configuration Information - Factory Integrated Models.
