HP ProLiant MicroServer: технические характеристики и документация

• New pre-configured BTO model with 4GB UDIMM

• Processor:
  • AMD Turion™ II Neo N54L (2.2GHz)
  • AMD RS785E/SB820M chipset
• Memory:
• Two (2) DIMM slots
• 4GB (1x4GB) Standard/8GB Maximum, using PC3-10600E DDR3 Unbuffered (UDIMM) ECC memory, operating at max. 800MHz
• Storage Controller:
• Embedded AMD SATA controller with RAID 0, 1
• Embedded AMD eSATA controller for connecting external storage devices via the eSATA connector in the rear of the server
• Internal Drive Support:
• 4 Internal HDD Support
• Maximum internal SATA storage capacity of up to 8.0TB (4 x 2TB 3.5" SATA drives)
• Network Controller:
• Embedded NC107i PCI Express Gigabit Ethernet Server Adapter
• Expansion Slots:
• Slot 1: PCI-Express Gen 2 x16 connector with x16 link
• Slot 2: PCI-Express Gen 2 x1 connector with x1 Link
• Slot 2-2: PCI-Express x4 slot for optional management card
• USB 2.0 Ports:
• Seven (7) USB 2.0 ports: 4 front , 2 rear, 1 internal (for tape)
• Power Supply:
• 150 Watts Non-Hot Plug, Non Redundant Power Supply
• Management:
• Optional MicroServer Remote Access Card
• Operating System:
• Supports Windows and Red Hat Linux

• Form Factor:
• Ultra Micro tower
• Warranty:
• This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners. Hardware diagnostic support and repair is available for one year from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HP Care Pack services or customized service agreements. Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.
  NOTE: Server Warranty includes 1 year Next Day Parts replacement, 0-Years Labor, 0-Years Onsite support. Additional information regarding worldwide limited warranty and technical support is available at: http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html.

PC3-10600E unbuffered DDR3 ECC operating at 800MHz

Expansion Slots #

128MB shared supporting 1920x1200 @ 60Hz

7 country specific, lowline NEMA power cord.

Microsoft Windows Server
Red Hat Enterprise Linux (RHEL)

HP Technology Services for Industry Standard Servers
HP Technology Services delivers confidence, reduces risk and helps customers realize agility and stability. Connect to HP to help prevent problems and solve issues faster. Our support technology lets you to tap into the knowledge of millions of devices and thousands of experts to stay informed and in control, anywhere, any time.

Protect your business beyond warranty with HP Care Pack Services
HP Care Pack Services enable you to order the right service level, length of coverage and response time as you purchase your new server, giving you full entitlement for the term you select.

Supports maintaining servers at optimum performance availability

Foundation Care 24x7, three-year Care Pack Service
HP Foundation Care 24x7 connects you to HP 24 hours a day, seven days a week for assistance on resolving issues. Hardware onsite response within four hours if needed; collaborative software included in this Care Pack service provides troubleshooting assistance on industry leading software running on your HP server. Simplify your support experience and make HP your first call for hardware or software questions.
http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=4AA4-8876ENW&cc=us&lc=en

Service recommendation that maintains high level of server availability

Foundation Care NBD, three-year Care Pack Service
HP Foundation Care Next Business Day connects you to HP during business hours for assistance on resolving issues - features next business day hardware onsite response if needed and software call back within two hours. Collaborative software support is included and provides troubleshooting assistance on industry leading software running on your server. Simplify your support experience and make HP your first call for hardware or software questions.
http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=4AA4-8876ENW&cc=us&lc=en

HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking options to assist you in bringing your new hardware into operation in a timely and professional manner.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf

Prevent problems with innovative, automated monitoring tools and proactive services. Combining Proactive Care Services with our remote support technology such as Insight Online provides you with expert advice and personalized, cloud-based automated IT support, helping to prevent unplanned down time and solve problems quickly. For more information, visit: www.hp.com/go/proactiveinsightexperience

HP will provide HP-supported replacement parts and materials necessary to maintain the covered hardware product in operating condition, including parts and materials for available and recommended engineering improvements.

Parts and components that have reached their maximum supported lifetime and/or the maximum usage limitations as set forth in the manufacturer's operating manual, product QuickSpecs, or the technical product data sheet will not be provided, repaired, or replaced as part of these services.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by HP due to malfunction.

To learn more on HP ProLiant servers and HP BladeSystem, please contact your HP sales representative or HP Authorized Channel Partner, or visit: www.hp.com/services/proliant or
www.hp.com/services/bladesystem

SATA Models
NOTE: Not all models are available in all regions. Check with your local country HP offices for availability.

HP ProLiant MicroServer G7 N54L 1P 4GB-U Non-hot Plug SATA 150W PS Server
744900-xx1

Maximum Storage Capacity

To review typical system power ratings use the Power Advisor which is available via the online tool located at URL: http://www.hp.com/go/hppoweradvisor

Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling programs in many geographic areas. For trade-in information, please go to: http://www.hp.com/go/green. To recycle your product, please go to: http://www.hp.com/go/green or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/green. These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.
