Dimensions and weight

The following table lists the height, width, depth, and weight of your Dell G15 5530.

Table 1. Dimensions and weightThe following table lists the height, width, depth, and weight of your Dell G15 5530.
Description		Values
Height:
	Front height	21.28 mm (0.83 in.)
	Rear height	26.15 mm (1.02 in.)
Width		357.26 mm (14.06 in.)
Depth		274.52 mm (10.80 in.)
Weight NOTE:The weight of your computer depends on the configuration that is offered.		2.81 kg (6.20 lb)

Processor

The following table lists the details of the processors that are supported by your Dell G15 5530.

Table 1. Processor
The following table provides the various processor options that are supported for Dell G15 5530.
Description		Option one	Option two	Option three	Option four
Processor type		13^th Generation Intel Core i5-13450HX	13^th Generation Intel Core i7-13650HX	13^th Generation Intel Core i7-13700HX	13^th Generation Intel Core i9-13900HX
Processor wattage		55 W	55 W	55 W	55 W
Processor total core count		10	14	16	24
Performance-cores		6	6	8	8
Efficient-cores		4	8	8	16
Processor total thread counts		16	20	24	32
		NOTE:Intel® Hyper-Threading Technology is only available on Performance-cores.
Performance-cores frequency
	Processor base frequency	2.40 GHz	2.60 GHz	2.10 GHz	2.20 GHz
	Maximum turbo frequency	Up to 4.60 GHz	Up to 4.90 GHz	Up to 5 GHz	Up to 5.40 GHz
Efficient-cores frequency
	Processor base frequency	1.80 GHz	1.90 GHz	1.50 GHz	1.60 GHz
	Maximum turbo frequency	3.40 GHz	3.60 GHz	3.70 GHz	3.90 GHz
		NOTE: Processor clock speeds and thermal design power differ according to the thermal mode selected in the MyDell (replaced with Dell Optimizer) app on your computer.
Processor cache		20 MB	24 MB	30 MB	36 MB
Integrated graphics		Intel UHD Graphics	Intel UHD Graphics	Intel UHD Graphics	Intel UHD Graphics

Chipset

The following table lists the details of the chipset that is supported in your Dell G15 5530.

Table 1. Chipset The following table lists the details of the chipset that is supported in your Dell G15 5530.
Description	Values
Chipset	HM770
Processor	13^th Generation Intel Core i5/i7/i9
DRAM bus width	64-bit
Flash EPROM	32 MB
PCIe bus	Up to Gen4

Operating system

Your Dell G15 5530 supports the following operating systems:

Windows 11 Professional, 64-bit
Windows 11 Home, 64-bit
Ubuntu 20.04 LTS, 64-bit

Memory

The following table lists the memory specifications that are supported by your Dell G15 5530.

Table 1. Memory specificationsThe following table lists the memory specifications of your computer.
Description	Values
Memory slots	Two SODIMM slots
Memory type	DDR5
Memory speed	4800 MT/s
Maximum memory configuration	32 GB
Minimum memory configuration	8 GB
Memory size per slot	8 GB or 16 GB
Memory configurations supported	8 GB, 1 x 8 GB, DDR5, 4800 MT/s 16 GB, 1 x 16 GB, DDR5, 4800 MT/s 16 GB, 2 x 8 GB, DDR5, 4800 MT/s, dual-channel 32 GB, 2 x 16 GB, DDR5, 4800 MT/s, dual-channel NOTE:When upgrading memory, Dell Technologies recommends replacing memory of the same capacity and speed in both the SODIMM slots to prevent compatibility and reliability issues. Ensure that the BIOS version is 1.6.0 or later when upgrading the memory.

External ports and slots

The following table lists the external ports and slots of your Dell G15 5530.

Table 1. External ports and slots
The following table lists ports and connectors available on Dell G15 5530.
Description	Values
Network port	One RJ-45 port
USB ports	Three USB 3.2 Gen 1 ports One USB 3.2 Gen 2 (Type-C) with DisplayPort
Audio port	One universal audio jack
Video port(s)	One HDMI 2.1 port
Media-card reader	Not supported
Power-adapter port	One 7.4 mm x 5.1 mm power-adapter port
Security-cable slot	Not supported

Internal slots

The following table lists the internal slots of your Dell G15 5530.

Table 1. Internal slotsThe following table lists the internal slots on your Dell G15 5530.
Description	Values
M.2	One M.2 2230 slot for Wi-Fi and Bluetooth combo card Two M.2 2230/2280 slots for solid-state drives NOTE:To learn more about the features of different types of M.2 cards, search in the Knowledge Base Resource at Dell Support Site.

Ethernet

The following table lists the wired Ethernet Local Area Network (LAN) specifications of your Dell G15 5530.

Table 1. Ethernet specifications
The following table provides the specifications of Ethernet that is supported by your Dell G15 5530.
Description	Values
Model	Realtek RTL8111H PCI-e 1 Gigabit Ethernet controller
Transfer rate	10/100/1000 Mbps

Wireless module

The following table lists the Wireless Local Area Network (WLAN) module that is supported on your Dell G15 5530.

Table 1. Wireless module specifications
The following table provides the wireless module specifications of Dell G15 5530.
Description	Values
Model number	Intel AX201
Transfer rate	2400 Mbps
Frequency bands supported	2.4 GHz/5 GHz
Wireless standards	Wi-Fi 802.11a/b/g Wi-Fi 4 (Wi-Fi 802.11n) Wi-Fi 5 (Wi-Fi 802.11ac) Wi-Fi 6 (Wi-Fi 802.11ax)
Encryption	64-bit/128-bit WEP AES-CCMP TKIP
Bluetooth wireless card	Bluetooth 5.2

Audio

The following table lists the audio specifications of your Dell G15 5530.

Table 1. Audio specifications
The following table provides the detailed audio specifications of Dell G15 5530.
Description		Values
Audio controller		Realtek ALC3204
Stereo conversion		Supported
Internal audio interface		High definition audio
External audio interface		One universal audio jack
Number of speakers		Two
Internal-speaker amplifier		Supported
External volume controls		Keyboard shortcut controls
Speaker output:
	Average	2 x 2 W = 4 W
	Peak	2 x 2.5 W = 5 W
Microphone		One microphone in camera assembly

Storage

This section lists the storage options on your Dell G15 5530.

Your Dell G15 5530 supports one of the following storage configurations:

One M.2 2230 or M.2 2280 solid-state drive
Two M.2 2230 or M.2 2280 solid-state drives

The primary drive of your Dell G15 5530 is installed in solid-state drive slot one.

Table 1. Storage specifications
The following table provides the different storage options available on Dell G15 5530.
Storage type	Interface type	Capacity
M.2 2230 solid-state drive	PCIe NVMe Gen4 x4	Up to 1 TB
M.2 2280 solid-state drive	PCIe NVMe Gen4 x4	Up to 2 TB

Keyboard

The following table lists the keyboard specifications of your Dell G15 5530.

Table 1. Keyboard specifications
The following table provides the detailed keyboard specifications of Dell G15 5530.
Description	Values
Keyboard type	Single-color backlit (white) keyboard Single-color backlit (hot coral) keyboard Four-zone RGB backlit keyboard
Keyboard layout	QWERTY
Number of keys	United States and Canada: 101 keys United Kingdom: 102 keys Japan: 105 keys
Keyboard size	X=18.70 mm key pitch Y=18.05 mm key pitch
Keyboard shortcuts	Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. To type the alternate character, press Shift and the desired key. To perform secondary functions, press Fn and the desired key. NOTE:You can define the primary behavior of the function keys (F1–F12) changing Function Key Behavior in the BIOS setup program. NOTE:If Copilot in Windows is not available on your computer, pressing the Copilot key launches Windows search. For more information about Copilot in Windows, search in the Knowledge Base Resource at the Dell Support site.

Keyboard shortcuts

NOTE:Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts remain the same across all language configurations.

Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. The symbol shown on the lower part of the key refers to the character that is typed out when the key is pressed. If you press Shift and the key, the symbol shown on the upper part of the key is typed out. For example, if you press 2, 2 is typed out; if you press Shift + 2, @ is typed out.

The keys F1 to F12 at the top row of the keyboard are function keys for multi-media control, as indicated by the icon at the bottom of the key. Press the function key to invoke the task represented by the icon. For example, pressing F1 mutes the audio (refer to the table below).

However, if the function keys F1 to F12 are needed for specific software applications, multi-media functionality can be disabled by pressing fn + Esc. Subsequently, multi-media control can be invoked by pressing fn and the respective function key. For example, mute audio by pressing fn + F1.

NOTE:You can also define the primary behavior of the function keys (F1 to F12) by changing Function Key Behavior in the BIOS Setup program.

Table 1. List of keyboard shortcuts
The following table lists the keyboard shortcuts and their descriptions.
Function key	Redefined key (for multimedia control)	Primary behavior
		Mute audio
		Decrease volume
		Increase volume
		Play/Pause
		Toggle keyboard backlight (optional)
		Decrease brightness
		Increase brightness
		Switch to external display
		Search/G key (optional)
		Print screen
		Home
		End
		Disable or enable the Windows key which activates the Windows Start screen when the Windows key is pressed. NOTE:Disabling the Windows key helps you to avoid accidental presses of the Windows key during gaming sessions.

The Fn key is also used with selected keys on the keyboard to invoke other secondary functions.

Table 2. Secondary behavior
The following table lists the keyboard shortcuts and their descriptions.
Function key	Secondary behavior
	Turn off/on wireless
	Pause/Break
	Insert
	Sleep
	Toggle between power and battery-status light/hard-drive activity light
	System request
	Open application menu
	Toggle fn-key lock
	Page up
	Page down
	Home
	End

Camera

The following table lists the camera specifications of your Dell G15 5530.

Table 1. Camera specifications
The following table provides the detailed camera specifications of Dell G15 5530.
Description		Values
Number of cameras		One
Camera type		HD RGB camera
Camera location		Front camera
Camera sensor type		CMOS sensor technology
Camera resolution:
	Still image	0.92 megapixel
	Video	1280 x 720 (HD) at 30 fps
Diagonal viewing angle		78.6 degrees

Touchpad

The following table lists the touchpad specifications of your Dell G15 5530.

Table 1. Touchpad specifications
The following table provides the detailed touchpad specifications of Dell G15 5530.
Description		Values
Touchpad resolution:
	Horizontal	1229
	Vertical	689
Touchpad dimensions:
	Horizontal	105 mm (4.13 in.)
	Vertical	60 mm (2.36 in.)
Touchpad gestures		For more information about the touchpad gestures that are available on: Windows, see the Microsoft Knowledge Base article at Microsoft Support Site. Ubuntu, see Ubuntu Support Site.

Power adapter

The following table lists the power adapter specifications of your Dell G15 5530.

Table 1. Power-adapter specifications
The following table provides the detailed power adapter specifications of Dell G15 5530.
Description		Option one	Option two	Option three
Type		180 W NOTE:The availability of computer configurations with a 180 W adapter may vary and may not be available in your specific country or region.	240 W	330 W
Connector dimensions:
	External diameter	7.40 mm (0.29 in.)	7.40 mm (0.29 in.)	7.40 mm (0.29 in.)
	Internal diameter	5.10 mm (0.20 in.)	5.10 mm (0.20 in.)	5.10 mm (0.20 in.)
Power-adapter dimensions:
	Height	30 mm (1.18 in.)	25.40 mm (1 in.)	43 mm (1.69 in.)
	Width	76.20 mm (3 in.)	100 mm (3.94 in.)	100 mm (3.94 in.)
	Depth	155 mm (6.10 in.)	200 mm (7.87 in.)	200 mm (7.87 in.)
Input voltage		100 VAC x 240 VAC	100 VAC x 240 VAC	100 VAC x 240 VAC
Input frequency		50 Hz x 60 Hz	50 Hz x 60 Hz	50 Hz x 60 Hz
Input current (maximum)		2.34 A	3.50 A	4.40 A
Output current (continuous)		2.34 A	12.31 A	16.92 A
Rated output voltage		19.50 VDC	19.50 VDC	19.50 VDC
Temperature range:
	Operating	0°C to 40°C (32°F to 104°F)	0°C to 40°C (32°F to 104°F)	0°C to 40°C (32°F to 104°F)
	Storage	-40°C to 70°C (-40°F to 158°F)	-40°C to 70°C (-40°F to 158°F)	-40°C to 70°C (-40°F to 158°F)
CAUTION:Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components.

Battery

The following table lists the battery specifications of your Dell G15 5530.

Table 1. Battery specifications
The following table provides the detailed battery specifications of Dell G15 5530.
Description		Option one	Option two
Battery type		3-cell, 56 Wh, Lithium-ion, ExpressCharge Boost	6-cell, 86 Wh, Lithium-ion, ExpressCharge Boost
Battery voltage		11.40 VDC	11.40 VDC
Battery weight (maximum)		0.25 Kg (0.56 lb)	0.34 kg (0.75 lb)
Battery dimensions:
	Height	7.56 mm (0.30 in.)	7.56 mm (0.30 in.)
	Width	77.70 mm (3.06 in.)	77.70 mm (3.06 in.)
	Depth	295.20 mm (11.62 in.)	295.20 mm (11.62 in.)
Temperature range:
	Operating	Charge: 0°C to 50°C (32°F to 122°F) Discharge: 0°C to 60°C (32°F to 140°F)	Charge: 0°C to 50°C (32°F to 122°F) Discharge: 0°C to 60°C (32°F to 140°F)
	Storage	–20°C to 65°C (-4°F to 149°F)	–20°C to 65°C (-4°F to 149°F)
Battery operating time		Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.	Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
Battery charging time (approximate)		Express Charge Method: 2 hours Standard Charge/Predominately AC User Charge Method: 3 hours Express Charge Boost Charge Method (Fast Charge for Initial 35%): From 0% up to 35% in as little as 20 minutes	Express Charge Method: 2 hours Standard Charge/Predominately AC User Charge Method: 3 hours Express Charge Boost Charge Method (Fast Charge for Initial 35%): From 0% up to 35% in as little as 20 minutes
Coin-cell battery		Not supported	Not supported
CAUTION:Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components. CAUTION:Dell Technologies recommends that you charge the battery regularly for optimal power consumption. If your battery charge is depleted, connect the power adapter, turn on your computer, and then restart your computer to reduce the power consumption.

Display

The following table lists the display specifications of your Dell G15 5530.

Table 1. Display specifications
The following table provides the detailed display specifications of Dell G15 5530.
Description		Option one	Option two	Option three	Option four
Display type		Full High Definition (FHD)	Full High Definition (FHD), ComfortView Plus	Full High Definition (FHD), ComfortView Plus	Quad-High Definition (QHD), ComfortView Plus
Display-panel technology		Wide-Viewing Angle (WVA)	Wide-Viewing Angle (WVA)	Wide-Viewing Angle (WVA)	Wide-Viewing Angle (WVA)
Display-panel dimensions (active area):
	Height	193.59 mm (7.62 in.)	193.59 mm (7.62 in.)	193.59 mm (7.62 in.)	193.59 mm (7.62 in.)
	Width	344.16 mm (13.55 in.)	344.16 mm (13.55 in.)	344.16 mm (13.55 in.)	344.16 mm (13.55 in.)
	Diagonal	395 mm (15.60 in.)	395 mm (15.60 in.)	394.87 mm (15.60 in.)	394.87 mm (15.60 in.)
Display-panel native resolution		1920 x 1080	1920 x 1080	1920 x 1080	2560 x 1440
Luminance (typical)		250 nits	300 nits	300 nits	400 nits
Megapixels		2.07	2.07	2.07	3.68
Color gamut		45% NTSC (typical)	100% sRGB (typical)	100% sRGB (typical)	99% DCI-P3 (typical)
Pixels Per Inch (PPI)		141	141	141	188
Contrast ratio (typical)		600:1 (minimum) 800:1 (typical)	800:1 (minimum) 1000:1 (typical)	800:1 (minimum) 1000:1 (typical)	800:1 (minimum) 1000:1 (typical)
Response time (maximum)		Tr+Tf: 25 ms (typical) Tr+Tf: 35 ms (maximum)	GtG with Overdrive: 3 ms (typical) GtG without Overdrive: 8 ms (typical)	GtG with Overdrive: 1 ms (typical)	GtG with Overdrive: 2 ms (typical)
Refresh rate		120 Hz	165 Hz	360 Hz	240 Hz
Horizontal view angle		+/- 85 degrees (typical)	+/- 85 degrees (typical)	+/- 85 degrees (typical)	+/- 85 degrees (typical)
Vertical view angle		+/- 85 degrees (typical)	+/- 85 degrees (typical)	+/- 85 degrees (typical)	+/- 85 degrees (typical)
Pixel pitch		0.17925 mm x 0.17925 mm	0.17925 mm x 0.17925 mm	0.17925 mm x 0.17925 mm	0.13446 mm x 0.13446 mm
Power consumption (maximum)		4.60 W	6 W	7.60 W	8.55 W
Anti-glare vs glossy finish		Anti-glare	Anti-glare	Anti-glare	Anti-glare
Touch options		No	No	No	No

GPU—Integrated

The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your Dell G15 5530.

Table 1. GPU—Integrated
The following table provides the detailed integrated graphics specifications of Dell G15 5530.
Controller	Memory size	Processor
Intel UHD Graphics	Shared system memory	13^th Generation Intel Core i5/i7/i9

GPU—Discrete

The following table lists the specifications of the discrete Graphics Processing Unit (GPU) supported by your Dell G15 5530.

Table 1. GPU—Discrete
The following table provides the detailed discrete graphics specifications of Dell G15 5530.
Controller	Memory size	Memory type
NVIDIA GeForce RTX 3050	6 GB	DDR6
NVIDIA GeForce RTX 4050	6 GB	DDR6
NVIDIA GeForce RTX 4060	8 GB	DDR6

Operating and storage environment

This table lists the operating and storage specifications of your Dell G15 5530.

Airborne contaminant level: G1 as defined by ISA-S71.04-1985

Table 1. Computer environment
The following table lists the operating and storage environment conditions of Dell G15 5530.
Description	Operating	Storage
Temperature range	0°C to 35°C (32°F to 95°F)	-40°C to 65°C (-40°F to 149°F)
Relative humidity (maximum)	10% to 90% (non-condensing)	0% to 95% (non-condensing)
Vibration (maximum)^*	0.66 GRMS	1.30 GRMS
Shock (maximum)	110 G†	160 G†
Altitude range	-15.2 m to 3048 m (4.64 ft to 5518.4 ft)	-15.2 m to 10668 m (4.64 ft to 19234.4 ft)
CAUTION:Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components.

^{* Measured using a random vibration spectrum that simulates the user environment.}

^{† Measured using a 2 ms half-sine pulse.}

ComfortView Plus

WARNING:Prolonged exposure to blue light from the display may lead to long-term effects such as eye strain, eye fatigue, or damage to the eyes.

Blue light is a color in the light spectrum which has a short wavelength and high energy. Chronic exposure to blue light, particularly from digital sources may disrupt sleep patterns and cause long-term effects such as eye strain, eye fatigue, or damage to the eyes.

The display on this computer is designed to minimize blue light and complies with TÜV Rheinland's requirement for low blue light displays.

Low blue light mode is enabled at the factory, so no further configuration is necessary.

To reduce the risk of eye strain, it is also recommended that you:

Position the display at a comfortable viewing distance between 20 and 28 inches (50 cm and 70 cm) from your eyes.
Blink frequently to moisten your eyes, wet your eyes with water, or apply suitable eye drops.
Take an extended break for 20 minutes every two hours.
Look away from your display, and gaze at a distant object at 20 ft (609.60 cm) away for at least 20 seconds during each break.
