Dell Pro 14 Premium PA14260: характеристики и спецификации

Dimensions and weight

The following table lists the height, width, depth, and weight of your Dell Pro 14 Premium PA14260.

Table 1. Dimensions and weightThe following table lists the height, width, depth, and weight of your Dell Pro 14 Premium PA14260.
Description	For computers shipped with WUXGA display	For computers shipped with WQXGA IPS display	For computers shipped with WQXGA Tandem OLED display	For computers shipped with WUXGA Lightweight display
Height:
Front height	0.45 in. (11.40 mm)	0.45 in. (11.40 mm)	0.43 in. (10.86 mm)	0.43 in. (10.95 mm)
Rear height	0.63 in. (16.02 mm)	0.63 in. (16.02 mm)	0.57 in. (14.59 mm)	0.59 in. (15 mm)
Peak height	0.78 in. (19.85 mm)	0.78 in. (19.85 mm)	0.66 in. (16.78 mm)	0.69 in. (17.60 mm)
Width	12.25 in. (311.20 mm)
Depth	8.53 in. (216.70 mm)
Weight NOTE:The weight of your computer depends on the configuration that you ordered.	Minimum: 2.88 lbs (1.31 kg)	Minimum: 2.68 lbs (1.22 kg)	Minimum: 2.61 lbs (1.19 kg)	Minimum: 2.53 lbs (1.15 kg)

Processor

The following table lists the details of the processors that are supported on your Dell Pro 14 Premium PA14260.

Table 1. Processor The following table lists the details of the processors that are supported on your Dell Pro 14 Premium PA14260.
Description	Option one	Option two	Option three
Type	Intel Core Ultra 5 335 vPro	Intel Core Ultra 7 365 vPro	Intel Core Ultra 7 366H vPro
Wattage	25 W	25 W	25 W
Total cores	8	8	16
Number of Performance-cores	4	4	4
Number of Efficient-cores	0	0	8
Number of low power efficient-cores	4	4	4
Total threads NOTE:: Intel Hyper-Threading Technology is only available on Performance-cores.	8	8	16
Speed	4.6 GHz	4.8 GHz	4.8 GHz
Performance-core frequency
Base frequency	2.2 GHz	2.4 GHz	2 GHz
Maximum turbo frequency	4.6 GHz	4.8 GHz	4.8 GHz
Efficient-core frequency
Base frequency	1.6 GHz	1.8 GHz	1.6 GHz
Maximum turbo frequency	3.4 GHz	3.6 GHz	3.6 GHz
Cache	12 MB	12 MB	18 MB
Integrated graphics	Intel Graphics	Intel Graphics	Intel Graphics
AI technology	Intel AI Boost	Intel AI Boost	Intel AI Boost
Neural Processing Unit (NPU) performance	47 TOPS	49 TOPS	50 TOPS
NOTE:Tera Operations Per Second (TOPS) is an AI performance metric that measures how many trillions of operations per second an AI processor can perform.

Chipset

The following table lists the details of the chipset that is supported by your Dell Pro 14 Premium PA14260.

Table 1. Chipset The following table lists the details of the chipset that is supported by your Dell Pro 14 Premium PA14260.
Description	Values
Chipset	Integrated in the processor
Processor	Intel Core Ultra 5/Intel Core Ultra 7
DRAM bus width	64-bit
Flash EPROM	64 MB
PCIe bus	Up to Gen4

Operating system

Your Dell Pro 14 Premium PA14260 supports the following operating systems:

Windows 11 25H2 and later versions.

Memory

The following table lists the memory specifications of your Dell Pro 14 Premium PA14260.

Table 1. Memory specifications
The following table provides the detailed memory specifications of Dell Pro 14 Premium PA14260.
Description		Values
Memory slots		Onboard memory NOTE:The memory is integrated on the system board and is not upgradeable.
Memory type		Dual-channel LPDDR5X
Memory speed		8533 MT/s (for Intel Core Ultra 7 366H vPro) 7467 MT/s (for Intel Core Ultra 5 335 vPro and Intel Core Ultra 7 365 vPro)
Maximum memory configuration		64 GB
Minimum memory configuration		16 GB
Memory configurations supported		For Intel Core Ultra 7 366H vPro: 16 GB: LPDDR5X, 8533 MT/s, dual-channel 32 GB: LPDDR5X, 8533 MT/s, dual-channel 64 GB: LPDDR5X, 8533 MT/s, dual-channel For Intel Core Ultra 5 335 vPro and Intel Core Ultra 7 365 vPro: 16 GB: LPDDR5X, 7467 MT/s, dual-channel 32 GB: LPDDR5X, 7467 MT/s, dual-channel

External ports and slots

The following table lists the external ports and slots on your Dell Pro 14 Premium PA14260.

Table 1. External ports and slots
The following table lists ports and connectors available on Dell Pro 14 Premium PA14260.
Description	Values
USB ports	Two Thunderbolt 4 (40 Gbps) with DisplayPort Alt Mode/USB Type-C/USB4/Power Delivery ports One USB 3.2 Gen 1 (5 Gbps) with PowerShare port
Audio port	One headset (headphone and microphone combo) port
Video port(s)	Two Thunderbolt 4 (40 Gbps) with DisplayPort Alt Mode/USB Type-C/USB4/Power Delivery ports One HDMI 2.1 port
Media-card reader	Not supported
Power-adapter port	Supported through one of the following: 65 W AC adapter, USB Type-C 60 W AC small form factor adapter, USB Type-C 60 W AC small form factor adapter, USB Type-C, 2-pin 100 W AC adapter, USB Type-C 65 W USB-C GAN Slim Adapter (2-pin, wall mount)
Security-cable slot	One security-cable slot (wedge-shaped)
SIM-card slot	One nanoSIM-card slot (optional)

Internal slots

The following table lists the internal slots of your Dell Pro 14 Premium PA14260.

Table 1. Internal slotsThe following table lists the internal slots on your Dell Pro 14 Premium PA14260.
Description	Values
M.2	One M.2 2230 slot for solid-state drive One M.2 3052 slot for 5G WWAN card NOTE:To learn more about the features of different types of M.2 cards, search Dell Support Site.

Wireless module

The following table lists the Wireless Local Area Network (WLAN) module that is supported on your Dell Pro 14 Premium PA14260.

Table 1. Wireless module specifications
The following table provides the wireless module specifications of Dell Pro 14 Premium PA14260.
Description	Values
Model number	Intel BE211
Transfer rate	Up to 5760 Mbps
Frequency bands supported	2.4 GHz/5 GHz/6 GHz
Wireless standards	Wi-Fi 802.11a/b/g Wi-Fi 4 (Wi-Fi 802.11n) Wi-Fi 5 (Wi-Fi 802.11ac) Wi-Fi 6E (Wi-Fi 802.11ax) Wi-Fi 7 (Wi-Fi 802.11be)
Encryption	64-bit/128-bit WEP AES-CCMP TKIP
Bluetooth wireless card NOTE:The functionality of the Bluetooth wireless card may vary based on the operating system.	Bluetooth 6.0 wireless card

WWAN module

The following table lists the Wireless Wide Area Network (WWAN) module that is supported in your Dell Pro 14 Premium PA14260.

NOTE: The WWAN module is available only on certain configurations and in certain regions.

NOTE:Availability of the eSIM feature on this module may vary depending on your region and the support that is offered by your mobile carrier.

NOTE:For instructions on how to setup SIM or eSIM connections on your computer, see the SIM/eSIM Setup Guide for Windows available with your product documentation at Dell Support Site.

Table 1. WWAN module specificationsThe following table lists the Wireless Wide Area Network (WWAN) module that is supported in your Dell Pro 14 Premium PA14260.
Description	Values
Model number	Qualcomm Snapdragon X72 Global 5G Modem (DW5934e)
Form factor	M.2 3052 Key-B
Host interface	PCIe Gen3
Network standard	NR FR1 (Sub6) FDD/TDD, LTE FDD/TDD, WCDMA/HSPA+, GPS/GLONASS/Galileo/Beidou
Transfer data rate	5G NR: DL 4.14 Gbps/UL 900 Mbps LTE: DL 2.0 Gbps (CAT20)/UL 211 Mbps (CAT18) UMTS: DL DC-HSPA+ Rel8:42 Mbps/UL 5.76 Mbps
Operating frequency bands	NR (n1, n2, n3, n5, n7, n8, n12, n13, n14, 18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n67, n70, n71, n75, n76, n77, n78, n79, n91, n92, n93, n94) LTE (B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B67, B68, B70, B71) WCDMA/HSPA+ (1, 2, 4, 5, 8)
Power supply	DC 3.135 V to 3.63 V, typical 3.30 V
SIM card	Supported through external SIM slot
eSIM with dual SIM (DSSA)	Supported NOTE:The availability of eSIM functionality embedded on the module is dependent on the region and specific carrier requirements.
Antenna diversity	Supported
Radio on/off	Supported
Wake On Wireless WAN	Not supported
Operating temperature	Normal operating temperature: -30°C (-22°F) to +70°C (158°F) Extended operating temperature: -40°C (-40°F) to +85°C (185°F) Storage temperature: -40°C (-40°F) to +85°C (185°F)
Antenna connector	WWAN main antenna x1 WWAN diversity antenna x1 4x4 MIMO antenna x2
NOTE:For instructions to find your computer's International Mobile Equipment Identity (IMEI) number, search Dell Support Site.

Audio

The following table lists the audio specifications of your Dell Pro 14 Premium PA14260.

Table 1. Audio specificationsThe following table provides the detailed audio specifications of Dell Pro 14 Premium PA14260.
Description		Values
Audio controller		Cirrus CS42L43 and Cirrus CS35L56A (AMP)
Stereo conversion		Supported
Internal audio interface		SoundWire audio interface
External audio interface		One headset (headphone and microphone combo) port
Number of speakers		Four
Internal-speaker amplifier		Supported (audio codec integrated) + CS35L56A (AMP)
External volume controls		Keyboard shortcut controls
Speaker output:
Average		2 W
Peak		2.5 W
Microphone		Digital-array microphones in camera assembly

Storage

This section lists the storage options on your Dell Pro 14 Premium PA14260.

Your Dell Pro 14 Premium PA14260 supports one M.2 2230 solid-state drive which is the primary drive of your computer.

Table 1. Storage specifications
The following table provides the different storage options available on Dell Pro 14 Premium PA14260.
Storage type	Interface type	Capacity
M.2 2230 solid-state drive	PCIe Gen4 NVMe	256 GB/512 GB/1 TB/2 TB
M.2 2230 solid-state drive, Self-encrypting drive, Opal 2.0	PCIe Gen4 NVMe	512 GB

Keyboard

The following table lists the keyboard specifications of your Dell Pro 14 Premium PA14260.

Table 1. Keyboard specificationsThe following table lists the keyboard specifications of your Dell Pro 14 Premium PA14260.
The following table provides the detailed keyboard specifications of Dell Pro 14 Premium PA14260.
Description	Values
Keyboard type	Zero-Lattice keyboard with battery-saving backlight
Keyboard layout	QWERTY
Number of keys	English US, English International, Arabic, Canada (Bilingual) (MUI), Chinese (Traditional), French (Canadian), Greek, Hebrew, Korean, Russian, Thai, Ukrainian: 79 keys French-Canadian Quebec, Belgian, Bulgarian, Czech/Slovak (MUI), Danish, English UK, Estonian, French (European), German, Hungarian, Icelandic, Italian, Nordic (MUI), Norwegian, Portuguese, Spanish (Castilian), Spanish (Latin America), Swedish/Finnish, Swiss European (MUI), Turkish, Turkish (F): 80 keys Japanese: 83 keys Portuguese (Brazil): 81 keys
Key pitch	Horizontal = 18.05 mm Vertical = 18.05 mm
Keyboard shortcuts	Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. To type the alternate character, press Shift and the desired key. To perform secondary functions, press Fn and the desired key. NOTE:You can define the primary behavior of the function keys (F1–F12) by changing Function Key Behavior in the BIOS Setup program. NOTE:If Co-pilot in Windows is not available on your computer, pressing the Co-pilot key launches Windows search. For more information about Co-pilot in Windows, search Dell Support site. For more information, see Keyboard function keys.

Keyboard shortcuts of Dell Pro 14 Premium PA14260

NOTE:Keyboard characters may differ depending on the keyboard language configuration. Keys that are used for shortcuts remain the same across all language configurations.

Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. The symbol that is shown on the lower part of the key refers to the character that is typed out when the key is pressed. If you press shift and the key, the symbol that is shown on the upper part of the key is typed out. For example, if you press 2, 2 is typed out; if you press Shift + 2, @ is typed out.

The keys F1-F12 at the top row of the keyboard are function keys for multimedia control, as indicated by the icon on the key. Press the function key to enable the task represented by the icon. For example, pressing F1 mutes the audio (see the table below).

However, if the function keys F1-F12 are needed for specific software applications, multimedia functionality can be disabled by pressing Fn + Esc. Later, multimedia control can be invoked by pressing Fn and the respective function key. For example, mute audio by pressing Fn + F1.

NOTE:You can also define the primary behavior of the function keys (F1–F12) by changing Function Key Behavior in the BIOS setup program.

Table 1. Function key primary behavior
The following table lists the keyboard shortcuts and their descriptions.
Function key	Primary behavior
F1	Mute or unmute audio
F2	Decrease volume
F3	Increase volume
F4	Microphone Mute
F5	Keyboard Illumination/Backlight
F6	Decrease brightness
F7	Increase brightness
F8	Switch to external display
F10	Print screen
F11	Home
F12	End

The Fn key is also used with selected keys on the keyboard to invoke secondary functions.

Table 2. Secondary behaviorThe following table lists the secondary behavior of each key with the Function (Fn) key.
Function key	Secondary behavior
Fn + S	Toggle Scroll lock
Fn + B	Pause the current process
Fn + Ctrl + B	Break command
Fn + R	Activate system request function
Fn + left arrow	Move the cursor to start of the line
Fn + right arrow	Move the cursor to end of the line
Fn + Shift + B	Enable unobstrusive mode to reduce onscreen distraction
Fn + Ctrl	Open the application menu
Fn + Esc	Toggle between multimedia and function key behavior
Fn + PgUp	Scroll up the document or page
Fn + PgDn	Scroll down the document or page
Fn + Home	Move to the beginning of the document
Fn + End	Move to the end of the document
Copilot	Launch Copilot in Windows NOTE: If Copilot in Windows is not available on your computer, the Copilot key launches Recall. If both Recall and Copilot in Windows are not available on your computer, the Copilot key launches Windows Search. For more information about Copilot in Windows and Recall, search in the Knowledge Base Resource at the Dell Support Site.

Camera

The following table lists the camera specifications of your Dell Pro 14 Premium PA14260.

Table 1. Camera specificationsThe following table provides the detailed camera specifications of Dell Pro 14 Premium PA14260.
Description			Values
Number of cameras			Two
Camera type			There are two camera options: IR Camera IR Camera with Presence Detection (Synaptics)
Camera location			Front
Camera sensor type			CMOS sensor technology
Camera resolution:
Still image			8.0 megapixel
Video			2560 x 1440 at 30 fps
Infrared camera resolution:
Video			640 x 360 at 30 fps
Diagonal viewing angle:
Camera			88.10 degrees
Infrared camera			86.60 degrees

Touchpad

The following table lists the touchpad specifications of your Dell Pro 14 Premium PA14260.

Table 1. Touchpad specificationsThe following table provides the detailed touchpad specifications of Dell Pro 14 Premium PA14260.
Description		Values
Touchpad resolution:		>300 DPI
Touchpad dimensions:
Horizontal		125 mm (4.92 in.)
Vertical		75 mm (2.95 in.)
Touchpad gestures		For more information about the touchpad gestures available on Windows, search Microsoft Support Site.

Touchpad with collaboration controls (optional)

The following table lists the touchpad specifications of your Dell Pro 14 Premium PA14260 (for computers shipped with Collaboration Touchpad).

Table 1. Touchpad specifications
The following table provides the detailed touchpad specifications of Dell Pro 14 Premium PA14260.
Description	Values
Touchpad type	Collaboration Touchpad
Collaboration controls on touchpad	Four controls are available to control video, share screen, chat, and mute functions during conference calls. The controls are visible on the touchpad during any conference calls. Compatible with Zoom and Microsoft Teams app.
Collaboration controls settings	Control brightness manually or configure icon brightness to automatically adjust to the ambient light. Customize settings to activate collaboration controls with a single tap or a double tap. Customize specific controls to be activated or deactivated.
Collaboration controls functionality	Video icon: Turn on or off the camera. White icon: The camera is turned on. Red icon: The camera is off. Share screen icon: Tap once to share your screen. Tap again to stop sharing. Chat icon: Show or hide the chat window. The icon blinks when you receive a new chat message. Microphone icon: Turn on or mute the microphone. White icon: The microphone is turned on. Red icon: The microphone is muted.
Required apps for collaboration controls	Dell Optimizer version 6.3 or higher Zoom Client version 5.9.3 or higher Microsoft Teams (Windows desktop) version 1.6.00.24078 and higher
Touchpad resolution:
Horizontal	>300 dpi
Vertical	Not supported
Touchpad dimensions:
Horizontal	125 mm (4.92 in.)
Vertical	71 mm (2.79 in.)
Touchpad gestures	For more information about touchpad gestures available on Windows, see the Microsoft Knowledge Base article at Microsoft Support Site.
NOTE:To enjoy the collaboration touchpad (CTP) controls feature on your keyboard, ensure that you have the latest versions of the Dell Optimizer app and Zoom or Microsoft Teams app that is installed on your computer. Dell Optimizer offers a modular installation which allows you to select the modules you want to install. Install the collaboration touchpad module within the Dell Optimizer app to enjoy the functionality of collaboration controls. For more information, search for Dell Optimizer in the Knowledge Base Resource at the Dell Support Site. NOTE:For more information about how to configure and use your collaboration controls, search for the Collaboration Touchpad Reference Guide in the Knowledge Base Resource at Dell Support Site. Or, watch the video at Dell Collaboration Touchpad.

Power adapter

The following table lists the power adapter specifications of your Dell Pro 14 Premium PA14260.

Table 1. Power-adapter specifications
The following table provides the detailed power adapter specifications of Dell Pro 14 Premium PA14260.
Description	Option one	Option two	Option three	Option four	Option five
Type	65 W AC adapter, USB Type-C	60 W AC small form factor adapter, USB Type-C	60 W AC small form factor adapter, USB Type-C, 2-pin	100 W AC adapter, USB Type-C	65 W USB-C GAN Slim Adapter (2-pin, wall mount)
Power-adapter dimensions:
Height	28 mm (1.10 in.)	22 mm (0.86 in)	55 mm (2.16 in.)	26.50 mm (1.04 in)	31.00 mm (1.22 in.)
Width	51 mm (2 in.)	55 mm (2.16 in.)	66 mm (2.59 in.)	60 mm (2.36 in.)	41.50 mm (1.63 in.)
Depth	122 mm (4.80 in.)	66 mm (2.59 in.)	22 mm (0.86 in)	122 mm (4.80 in.)	48.50 mm (1.91 in.)
Input voltage	100 VAC–240 VAC	100 VAC–240 VAC	100 VAC–240 VAC	100 VAC–240 VAC	100 VAC–240 VAC
Input frequency	50 Hz–60 Hz	50 Hz–60 Hz	50 Hz–60 Hz	50 Hz–60 Hz	50 Hz–60 Hz
Input current (maximum)	1.7 A	1.7 A	1.7 A	1.7 A	1.7 A
Output current (continuous)	3 A/3 A/3 A/3.25 A	20 V/3 A (continuous) 15 V/3 A (continuous) 9 V/3 A (continuous) 5 V/3 A (continuous)	20 V/3 A (continuous) 15 V/3 A (continuous) 9 V/3 A (continuous) 5 V/3 A (continuous)	20 V/5 A 15 V/3 A 9 V/3 A 5 V/3 A	20 V/3.25 A 15 V/3 A 9 V/3 A 5 V/3 A
Rated output voltage	19.50 V	20 VDC/15 VDC/9 VDC/5 VDC	20 VDC/15 VDC/9 VDC/5 VDC	20 VDC 15 VDC 9 VDC 5 VDC	20 VDC 15 VDC 9 VDC 5 VDC
Temperature range:
Operating	0°C to 40°C (32°F to 104°F)	0°C to 40°C (32°F to 104°F)	0°C to 40°C (32°F to 104°F)	0°C to 35°C (32°F to 95°F)	0°C to 45°C (32°F to 109°F)
Storage	-40°C to 70°C (-40°F to 158°F)	-40°C to 70°C (-40°F to 158°F)	-40°C to 70°C (-40°F to 158°F)	-40°C to 70°C (-40°F to 158°F)	-40°C to 70°C (-40°F to 158°F)
CAUTION:Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components.

Power adapter requirements

NOTE:If you did not purchase the Dell-branded power adapter that is recommended for your computer, ensure that the power adapter you use meets the following requirements.

The following table lists the power adapter requirements for your Dell Pro 14 Premium PA14260.

Table 1. Power adapter requirementsThe following table lists the power adapter requirements for your Dell Pro 14 Premium PA14260.
Description	Value
Power that is required from a power adapter to achieve optimal performance.	65 W
Power that charges the computer at a slower speed. NOTE:A warning message may appear informing you about the use of a lower-powered adapter and slower charging speed.	Less than 60 W
Minimum power that is required from a power adapter to operate the computer and charge the battery. NOTE:A warning message appears informing you about the use of a lower-powered adapter and slower charging speed.	27 W
USB Power Delivery (PD) fast charging	Supported
ExpressCharge mode	Supported NOTE:Ensure that the computer with a 45 Wh battery is connected to a 65 W power adapter for this feature to be supported.

Battery

The following table lists the battery specifications of your Dell Pro 14 Premium PA14260.

Table 1. Battery specifications
The following table provides the detailed battery specifications of Dell Pro 14 Premium PA14260.
Description	Option one	Option two
Battery type	2-cell, 40 Wh, Lithium Ion Polymer, Long Life Cycle	3-cell, 60 Wh, Lithium Ion Polymer, Long Life Cycle
Battery voltage	7.80 VDC	11.70 VDC
Battery weight (maximum)	155 gm	215 gm
Battery dimensions:
Height	6.15 mm (0.24 in.)	6.15 mm (0.24 in.)
Width	248 mm (9.76 in.)	248 mm (9.76 in.)
Depth	65.10 mm (2.56 in.)	65.10 mm (2.56 in.)
Temperature range:
Operating	0°C to 60°C (32°F to 140°F)	0°C to 60°C (32°F to 140°F)
Storage	–20°C to 60°C (-4°F to 140°F)	–20°C to 60°C (-4°F to 140°F)
Battery operating time	Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.	Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
Battery charging time (approximate) NOTE:You can control the charging time, duration, start and end time, and so on, using the settings on the Dell Optimizer application. For more information about Dell Optimizer application, search Dell Support Site.	Express Charge Method: 0°C - 15°C maximum allowable charge time from 0 to 100% RSOC is 4 hours 16°C - 45°C normal express charge 46°C - 50°C maximum allowable charge time from 0 to 100% RSOC is 3 hours Standard Charge/Predominately AC User Charge Method: 0°C - 15°C maximum allowable charge time from 0 to 100% RSOC is 4 hours 16°C - 50°C maximum allowable charge time from 0 to 100% RSOC is 3 hours Express Charge Boost Charge Method (Fast Charge for Initial 35%): 16°C - 45°C target charge time from 0 to 35% RSOC is 20 mins for Accelerated Charge	Express Charge Method: 0°C - 15°C maximum allowable charge time from 0 to 100% RSOC is 4 hours 16°C - 45°C normal express charge 46°C - 50°C maximum allowable charge time from 0 to 100% RSOC is 3 hours Standard Charge/Predominately AC User Charge Method: 0°C - 15°C maximum allowable charge time from 0 to 100% RSOC is 4 hours 16°C - 50°C maximum allowable charge time from 0 to 100% RSOC is 3 hours Express Charge Boost Charge Method (Fast Charge for Initial 35%): 16°C - 45°C target charge time from 0 to 35% RSOC is 20 mins for Accelerated Charge
Coin-cell battery	Not supported	Not supported
CAUTION:Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components. CAUTION:Dell Technologies recommends that you charge the battery regularly for optimal power consumption.

Power requirements (for 2-cell, 40 Wh battery)

NOTE: The information in this section is applicable to the European Union (EU) countries.

Figure 1. Pictogram for power charging requirements

The power that is delivered by the charger must be between a minimum of 27 Watts that is required by the radio equipment, and a maximum of 76 Watts in order to achieve the maximum charging speed.

This computer supports USB Power Delivery (PD) fast charging.

Power requirements (for 3-cell, 60 Wh battery)

NOTE: The information in this section is applicable to the European Union (EU) countries.

The power that is delivered by the charger must be between a minimum of 27 Watts that is required by the radio equipment, and a maximum of 79 Watts in order to achieve the maximum charging speed.

This computer supports USB Power Delivery (PD) fast charging.

Display

The following table lists the display specifications of your Dell Pro 14 Premium PA14260.

Table 1. Display specifications
The following table provides the detailed display specifications of Dell Pro 14 Premium PA14260.
Description	Option one	Option two	Option three	Option four
Display type	14" Widescreen Ultra Extended Graphics Array (WUXGA)	14" Widescreen Ultra Extended Graphics Array (WUXGA) Lightweight	14" Wide Quad Extended Graphics Array (WQXGA)	14" Wide Quad Extended Graphics Array (WQXGA)
Display-panel technology	Wide Viewing Angle (WVA)	Wide Viewing Angle (WVA)	OLED, Wide Viewing Angle (WVA) NOTE:Computers with the WQXGA OLED configuration are only installed with the 3-cell, 60 Wh battery.	In-Plane Switching (IPS)
Display-panel dimensions (active area):
Height	188.50 mm (7.42 in.)	188.50 mm (7.42 in.)	188.50 mm (7.42 in.)	188.50 mm (7.42 in.)
Width	301.60 mm (11.87 in.)	301.60 mm (11.87 in.)	301.60 mm (11.87 in.)	301.60 mm (11.87 in.)
Diagonal	355.60 mm (14 in.)	355.60 mm (14 in.)	355.60 mm (14 in.)	355.60 mm (14 in.)
Display-panel native resolution	1920 x 1200	1920 x 1200	2880 x 1800	2560 x 1600
Luminance (typical)	400 nits	500 nits	400 nits	400 nits
Megapixels	2.30	2.30	5.18	4.1
Color gamut	45% NTSC	100% sRGB	100% DCI-P3	100% sRGB
Pixels Per Inch (PPI)	162	162	242	216
Contrast ratio (typical)	800:1	1500:1	1000000:1	1200:1
Response time (maximum)	35 milliseconds	35 milliseconds	2 milliseconds	35 milliseconds
Refresh rate	48 Hz-60 Hz	30 Hz-60 Hz	30 Hz-60 Hz	48 Hz-60 Hz
Horizontal view angle	89 degrees	89 degrees	89 degrees	89 degrees
Vertical view angle	89 degrees	89 degrees	89 degrees	89 degrees
Pixel pitch	0.157 mm	0.157 mm	0.105 mm	0.118 mm
Power consumption (maximum)	3.68 W	3.03 W	5.63 W	3.75 W
Anti-glare vs glossy finish	Anti-Glare	Anti-Glare	Anti-Reflect, Narrow Border, Corning Gorilla Glass	Anti-Glare
Touch options	No	No	Yes, fingertouch support	Yes, no pen support

Fingerprint reader (optional)

The following table lists the specifications of the optional fingerprint-reader of your Dell Pro 14 Premium PA14260.

Table 1. Fingerprint reader specifications
The following table provides the specifications of fingerprint reader of Dell Pro 14 Premium PA14260.
Description	Values
Sensor technology	Trans-capacitive sensing
Sensor resolution	500 dpi
Sensor pixel size	108 mm x 88 mm

Sensors

The following table lists the sensors of your Dell Pro 14 Premium PA14260.

Table 1. Sensors The following table lists the sensors of your Dell Pro 14 Premium PA14260.
Sensors support
Ambient Light Sensor (ALS)
Low-power vision AI-based user-presence detection
Accelerometer (for positional sensing)
Proximity for SAR compliance (for the WWAN module) near-field proximity sensor
Hall-Effect sensor (lid close)
Sensor hub

GPU—Integrated

The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your Dell Pro 14 Premium PA14260.

Table 1. GPU—Integrated
The following table provides the detailed integrated graphics specifications of Dell Pro 14 Premium PA14260.
Controller	Memory size	Processor
Intel Graphics	Shared system memory	Intel Core Ultra 5/Intel Core Ultra 7

External display support

The following table lists the external display support for your Dell Pro 14 Premium PA14260.

Table 1. External display supportThe following table lists the external display support for your Dell Pro 14 Premium PA14260.
Graphics card	Supported external displays with laptop display enabled	Supported external displays with laptop display disabled
Intel Graphics	3	4

Hardware security

The following table lists the hardware security of your Dell Pro 14 Premium PA14260.

Table 1. Hardware security The following table provides the hardware security details on your Dell Pro 14 Premium PA14260.
Hardware security
One wedge-shaped lock slot
Chassis Intrusion Detection
FIPs 140-2 certification
Trusted Platform Module TPM 2.0
Trusted Computing Group (TCG) certification for TPM
Touch fingerprint reader (palmrest/powerbutton/MoH/MoC/CV3)
SED SSD NVMe, SSD, and hard drive (Opal and non-Opal) per SDL
Statement of Non‑Volatile Random‑Access Memory (NVRAM)
Windows Hello - Fingerprint Reader (optional)
Mechanical privacy shutter for camera

Operating and storage environment

This table lists the operating and storage specifications of your Dell Pro 14 Premium PA14260.

Airborne contaminant level: G1 as defined by ISA-S71.04-1985

Table 1. Computer environment
The following table lists the operating and storage environment conditions of Dell Pro 14 Premium PA14260.
Description	Operating	Storage
Temperature range	0°C to 35°C (32°F to 95°F)	-40°C to 65°C (-40°F to 149°F)
Relative humidity (maximum)	10% to 90% (non-condensing)	0% to 95% (non-condensing)
Vibration (maximum)^*	0.66 GRMS	1.30 GRMS
Shock (maximum)	110 G†	160 G†
Altitude range	-15.2 m to 3048 m (-49.87 ft to 10,000 ft)	-15.2 m to 10,668 m (-49.87 ft to 35,000 ft)
CAUTION:Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components.

^{* Measured using a random vibration spectrum that simulates the user environment.}

^{† Measured using a 2 ms half-sine pulse.}

Dell low blue light display

WARNING:Prolonged exposure to blue light from the display may lead to long-term effects such as eye strain, eye fatigue, or damage to the eyes.

Blue light is a color in the light spectrum which has a short wavelength and high energy. Chronic exposure to blue light, particularly from digital sources may disrupt sleep patterns and cause long-term effects such as eye strain, eye fatigue, or damage to the eyes.

The display on this computer is designed to minimize blue light and complies with TÜV Rheinland's requirement for low blue light displays.

Low blue light mode is enabled at the factory, so no further configuration is necessary.

To reduce the risk of eye strain, it is also recommended that you:

Position the display at a comfortable viewing distance between 20 and 28 inches (50 cm and 70 cm) from your eyes.
Blink frequently to moisten your eyes, wet your eyes with water, or apply suitable eye drops.
Take an extended break for 20 minutes every two hours.
Look away from your display, and gaze at a distant object at 20 ft (609.60 cm) away for at least 20 seconds during each break.

Dell Optimizer

Dell Optimizer is an AI-based software application that allows you to customize your computer settings for power and battery, collaboration touchpad, and more.

For Dell Pro 14 Premium PA14260 with Dell Optimizer, you can:

Extend the battery life of your computer with Intelligent Battery Extender and Dynamic Charge.
Tune the performance, power consumption, cooling, and fan noise with selectable thermal modes.
Access Zoom and Microsoft Teams meeting controls with the Collaboration Touchpad.
Access and secure your computer depending on your physical presence.
Download and redeem the apps that are purchased with your computer.

For more information about configuring and using these features, search for Dell Optimizer at the Dell Support Site.

Dell support policy

For information about Dell support policy, search Dell Support Site.

Dell Pro 14 Premium PA14260: технические характеристики и спецификации
