Dell Pro Education 11 PE11260 2-in-1: характеристики и спецификации

Dimensions and weight

The following table lists the height, width, depth, and weight of your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Dimensions and weightThe following table lists the height, width, depth, and weight of your Dell Pro Education 11 PE11260 2-in-1.
Description		Values
Front height		21.90 mm (0.86 in.)
Rear height		21.90 mm (0.86 in.)
Width		303.90 mm (11.96 in.)
Depth		207.90 mm (8.19 in.)
Weight NOTE:The weight of your computer depends on the configuration that you ordered.		1.56 kg (3.45 lb)

Processor

The following table lists the details of the processors that are supported on your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Processor The following table lists the details of the processors that are supported on your Dell Pro Education 11 PE11260 2-in-1.
Description	Option one	Option two
Type	Intel Processor N150	Intel Processor N250
Wattage	6 W	6 W
Total cores	4	4
Number of Efficient-cores	4	4
Total threads NOTE:: Intel Hyper-Threading Technology is only available on Performance-cores.	4	4
Speed	3.6 GHz	3.8 GHz
Efficient-core frequency
Base frequency	0.8 GHz	1.3 GHz
Maximum turbo frequency	3.6 GHz	3.8 GHz
Cache	6 MB	6 MB
Integrated graphics	Intel Graphics	Intel Graphics

Chipset

The following table lists the details of the chipset that is supported by your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Chipset The following table lists the details of the chipset that is supported by your Dell Pro Education 11 PE11260 2-in-1.
Description	Values
Chipset	FCBGA1264
Processor	Intel Processor N150 Intel Processor N250
DRAM bus width	64-bit
Flash EPROM	32 MB
PCIe bus	Up to Gen3

Operating system

Your Dell Pro Education 11 PE11260 2-in-1 supports the following operating systems:

Windows 11 Home
Windows 11 Professional

Memory

The following table lists the memory specifications that are supported by your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Memory specificationsThe following table lists the memory specifications of your computer.
Description	Values
Memory slots	Onboard NOTE:Memory is non-upgradable.
Memory type	LPDDR5/LPDDR5x
Memory speed	4800 MT/s
Maximum memory configuration	8 GB
Minimum memory configuration	4 GB
Memory size per slot	Memory onboard
Memory configurations supported	4 GB: 1 x 4 GB, LPDDR5/LPDDR5x, 4800 MT/s, single channel (onboard) 8 GB: 1 x 8 GB, LPDDR5/LPDDR5x, 4800 MT/s, single channel (onboard)

External ports and slots

The following table lists the external ports and slots on your Dell Pro Education 11 PE11260 2-in-1.

Table 1. External ports and slots
The following table lists ports and connectors available on Dell Pro Education 11 PE11260 2-in-1.
Description	Values
USB ports	2 USB 3.2 Gen 1 (5 Gbps) Type-C with DisplayPort Alt Mode ports 1 USB 3.2 Gen 1 (5 Gbps) Type-A port
Audio port	One global headset jack
Video port(s)	2 USB 3.2 Gen 1 (5 Gbps) Type-C with DisplayPort Alt Mode ports
Media-card reader	Not supported
Power-adapter port	65 W AC adapter, USB Type-C
Security-cable slot	One wedge-shaped lock slot

Wireless module

The following table lists the Wireless Local Area Network (WLAN) module that is supported on your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Wireless module specifications
The following table provides the wireless module specifications of Dell Pro Education 11 PE11260 2-in-1.
Description	Values
Model number	Intel Wi-Fi 6E AX211 NOTE:WLAN is onboard and non-upgradable.
Transfer rate	Up to 2400 Mbps
Frequency bands supported	2.4 GHz 5 GHz 6 GHz
Wireless standards	Wi-Fi 802.11a/b/g Wi-Fi 4 (WiFi 802.11n) Wi-Fi 5 (WiFi 802.11ac) Wi-Fi 6E (WiFi 802.11ax)
Encryption	128-bit AES-CCMP 256-bit AES-GCMP
Bluetooth wireless card NOTE:The functionality of the Bluetooth wireless card may vary based on the operating system.	Bluetooth 5.4 wireless card

Audio

The following table lists the audio specifications of your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Audio specificationsThe following table provides the detailed audio specifications of Dell Pro Education 11 PE11260 2-in-1.
Description		Values
Audio controller		Realtek ALC3204
Stereo conversion		Supported
Internal audio interface		High definition audio interface
External audio interface		One global headset jack
Number of speakers		2
Internal-speaker amplifier		Not applicable
External volume controls		Keyboard shortcut controls
Speaker output:
Average		2 W
Peak		2.5 W
Microphone		Digital-array microphones in camera assembly

Storage

This section lists the storage options on your Dell Pro Education 11 PE11260 2-in-1.

Your Dell Pro Education 11 PE11260 2-in-1supports one of the following storage configurations:

One Universal Flash Storage
One M.2 2230 solid state drive

Table 1. Storage specifications
The following table provides the different storage options available on Dell Pro Education 11 PE11260 2-in-1.
Storage type	Interface type	Capacity
Universal Flash Storage	UFS v3.1, up to HS-Gear 4, 2.9 GB/s	128 GB
M.2 2230 solid state drive	PCIe Gen4 NVMe, up to 64 Gbps	256 GB

Keyboard

The following table lists the keyboard specifications of your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Keyboard specificationsThe following table lists the keyboard specifications of your Dell Pro Education 11 PE11260 2-in-1.
The following table provides the detailed keyboard specifications of Dell Pro Education 11 PE11260 2-in-1.
Description	Values
Keyboard type	Non-backlit keyboard
Keyboard layout	QWERTY
Number of keys	Non-backlit keyboard without numpad Arabic, English International, English US, French (Canadian): 79 keys Belgian, English UK, French (European), German, Hungarian, Italian, Nordic (MUI), Spanish (Castillian), Spanish (Latin America), Swiss European (MUI): 80 keys Japanese: 83 keys
Key pitch	Horizontal = 18.70 mm Vertical = 18.50 mm
Keyboard shortcuts	Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. To type the alternate character, press Shift and the desired key. To perform secondary functions, press Fn and the desired key. NOTE:You can define the primary behavior of the function keys (F1–F12) by changing Function Key Behavior in the BIOS Setup program. NOTE:If Copilot in Windows is not available on your computer, pressing the Copilot key launches Windows search. For more information about Copilot in Windows, search Dell Support site.

Keyboard shortcuts

NOTE:Keyboard characters may differ depending on the keyboard language configuration. Keys that are used for shortcuts remain the same across all language configurations.

Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. The symbol that is shown on the lower part of the key refers to the character that is typed out when the key is pressed. If you press shift and the key, the symbol that is shown on the upper part of the key is typed out. For example, if you press 2, 2 is typed out; if you press Shift + 2, @ is typed out.

The keys F1-F12 at the top row of the keyboard are function keys for multimedia control, as indicated by the icon at the bottom of the key. Press the function key to invoke the task represented by the icon. For example, pressing F1 mutes the audio (refer to the table below).

However, if the function keys F1-F12 are needed for specific software applications, multimedia functionality can be disabled by pressing Fn + Esc. Subsequently, multimedia control can be invoked by pressing Fn and the respective function key. For example, mute audio by pressing Fn + F1.

NOTE:You can also define the primary behavior of the function keys (F1–F12) by changing Function Key Behavior in BIOS setup program.

Table 1. List of keyboard shortcuts
The following table lists the keyboard shortcuts and their descriptions.
Function key	Redefined key (for multimedia control)	Behavior
F1	Fn + F1	Mute audio
F2	Fn + F2	Decrease volume
F3	Fn + F3	Increase volume
F4	Fn + F4	Play/pause
F5	Fn + F5	Decrease brightness
F6	Fn + F6	Increase brightness
F7	Fn + F7	Calculator
F8	Fn + F8	Win + P
F9	Fn + F9	Print screen
F10	Fn + F10	Home
F11	Fn + F11	End
F12	Fn + F12	Insert

The Fn key is also used with selected keys on the keyboard to invoke other secondary functions.

Table 2. Secondary behaviorThe following table lists the secondary behavior of each key with the Function (Fn) key.
Function key	Behavior
Fn + PrtScr	Print screen
Fn + B	Pause/Break
Fn + Insert	Insert
Fn + K	Toggle scroll lock
Fn + S	Print screen
Fn + Ctrl	Open application menu
Fn + Esc	Toggle Fn-key lock
Fn + PgUp	Page up
Fn + PgDn	Page down
Fn + Home	Home
Fn + End	End

Camera

The following table lists the camera specifications of your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Camera specificationsThe following table lists the camera specifications of your Dell Pro Education 11 PE11260 2-in-1.
Description	Option one	Option two
Number of cameras	One	One
Camera type	HD RGB Camera	5M RGB Camera
Camera location	Front camera	Rear camera
Camera sensor type	CMOS sensor technology	CMOS sensor technology
Camera resolution:
Still image	0.92 megapixels	4.92 megapixels
Video	1280 x 720 (HD) at 30 fps	2560 x 1920 (5M) at 30 fps
Diagonal viewing angle	83.50 degrees	76.6 degrees

Touchpad

The following table lists the touchpad specifications of your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Touchpad specificationsThe following table provides the detailed touchpad specifications of Dell Pro Education 11 PE11260 2-in-1.
Description		Values
Touchpad resolution:		>300 DPI
Touchpad dimensions:
Horizontal		100 mm
Vertical		55 mm
Touchpad gestures		For more information about the touchpad gestures available on Windows, search Microsoft Support Site.

Power adapter

The following table lists the power adapter specifications of your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Power-adapter specificationsThe following table provides the detailed power adapter specifications of Dell Pro Education 11 PE11260 2-in-1
Description		Values
Type		65 W AC adapter, USB Type-C
Power-adapter dimensions:
Height		28 mm (1.10 in.)
Width		51 mm (2.01 in.)
Depth		112 mm (4.41 in.)
Input voltage		100 VAC - 240VAC
Input frequency		50 Hz - 60 Hz
Input current (maximum)		1.70 A
Output current (continuous)		20 V/3.25 A (continuous) 15 V/3 A (continuous) 9 V/3 A (continuous) 5 V/3 A (continuous)
Rated output voltage		20 VDC/15 VDC/9 VDC/5 VDC
Temperature range:
Operating		0°C to 40°C (32°F to 104°F)
Storage		-40°C to 70°C (-40°F to 158°F)
CAUTION:Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components.

Power adapter requirements

NOTE:If you did not purchase the Dell-branded power adapter that is recommended for your computer, ensure that the power adapter you use meets the following requirements.

The following table lists the power adapter requirements for your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Power adapter requirementsThe following table lists the power adapter requirements for your Dell Pro Education 11 PE11260 2-in-1.
Description	Value
Power that is required from a power adapter to achieve optimal performance.	65 W
Power that charges the computer at a slower speed. NOTE:A warning message may appear informing you about the use of a lower-powered adapter and slower charging speed.	Less than 45 W
Minimum power that is required from a power adapter to operate the computer and charge the battery. NOTE:A warning message appears informing you about the use of a lower-powered adapter and slower charging speed.	27 W
USB Power Delivery (PD) fast charging	Supported
ExpressCharge mode	Supported NOTE:Ensure that the computer with a 45 Wh battery is connected to a 65 W power adapter for this feature to be supported.

Battery

The following table lists the battery specifications of your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Battery specifications
The following table provides the detailed battery specifications of Dell Pro Education 11 PE11260 2-in-1.
Description	Option one	Option two
Battery type	3-cell, 45 Wh, Lithium Ion	3-cell, 55 Wh, Lithium Ion
Battery voltage	13.2 VDC	13.50 VDC
Battery weight (minimum)	0.200 Kg (0.44 lb)	0.22 kg (0.48 lb)
Battery dimensions:
Height	6.3 mm (0.25 in.)	6.3 mm (0.25 in.)
Width	254.8 mm (10.03 in.)	254.8 mm (10.03 in.)
Depth	72.8 mm (2.87 in.)	72.8 mm (2.87 in.)
Temperature range:
Operating	0°C to 60°C (32°F to 140°F)	0°C to 60°C (32°F to 140°F)
Storage	-20°C to 65°C (-4°F to 149°F)	-20°C to 65°C (-4°F to 149°F)
Battery operating time	Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.	Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
Battery charging time (approximate)	0°C~15°C: 4 hours (when the computer is off) 16°C~45°C: 3 hours (when the computer is off) 46°C~50°C: 3 hours (when the computer is off)	0°C~15°C: 4 hours (when the computer is off) 16°C~45°C: 3 hours (when the computer is off) 46°C~50°C: 3 hours (when the computer is off)
Coin-cell battery	Not applicable	Not applicable
CAUTION:Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components. CAUTION:Dell Technologies recommends that you charge the battery regularly for optimal power consumption. If your battery charge is depleted, connect the power adapter, turn on your computer, and then restart your computer to reduce the power consumption.

Power requirements (for computers shipped with 3-cell, 45 Wh battery)

NOTE: The information in this section is applicable to the European Union (EU) countries.

Figure 1. Pictogram for power charging requirements

The power that is delivered by the charger must be between a minimum of 27 Watts that is required by the radio equipment, and a maximum of 63 Watts in order to achieve the maximum charging speed.

This computer supports USB Power Delivery (PD) fast charging.

Power requirements (for computers shipped with 3-cell, 55 Wh battery)

NOTE: The information in this section is applicable to the European Union (EU) countries.

The power that is delivered by the charger must be between a minimum of 27 Watts that is required by the radio equipment, and a maximum of 65 Watts in order to achieve the maximum charging speed.

This computer supports USB Power Delivery (PD) fast charging.

Display

The following table lists the display specifications of your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Display specifications
The following table provides the detailed display specifications of Dell Pro Education 11 PE11260 2-in-1.
Description		Values
Display type		11.6-inch High Definition (HD)
Touch options		Yes
Display-panel technology		In-Plane Switching (IPS)
Display-panel dimensions (active area):
Height		144 mm (5.67 in.)
Width		256.13 mm (10.08 in.)
Diagonal		294.64 mm (11.60 in.)
Display-panel native resolution		1366 x 768
Luminance (typical)		220 nits
Megapixels		1.04
Color gamut		50% NTSC
Pixels Per Inch (PPI)		135 ppi
Contrast ratio (minimum)		600:1 typical
Response time (maximum)		30 milliseconds
Refresh rate		60 Hz
Horizontal view angle		+ 80/- 80 degrees
Vertical view angle		+ 80/- 80 degrees
Pixel pitch		0.1875 mm x 0.1875 mm
Power consumption (maximum)		3 W
Anti-glare vs glossy finish		Glossy finish

GPU—Integrated

The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your Dell Pro Education 11 PE11260 2-in-1.

Table 1. GPU—Integrated
The following table provides the detailed integrated graphics specifications of Dell Pro Education 11 PE11260 2-in-1.
Controller	Memory size	Processor
Intel Graphics	Shared system memory	Intel Processor N150 Intel Processor N250

Hardware security

The following table lists the hardware security of your Dell Pro Education 11 PE11260 2-in-1.

Table 1. Hardware security The following table provides the hardware security details on your Dell Pro Education 11 PE11260 2-in-1.
Hardware security
One wedge-shaped lock slot

Operating and storage environment

This table lists the operating and storage specifications of your Dell Pro Education 11 PE11260 2-in-1.

Airborne contaminant level: G1 as defined by ISA-S71.04-1985

Table 1. Computer environment
The following table lists the operating and storage environment conditions of Dell Pro Education 11 PE11260 2-in-1.
Description	Operating	Storage
Temperature range	0°C to 35°C (32 °F to 95°F)	-40°C to 65°C (-40°F to 149°F)
Relative humidity (maximum)	10% to 90% (non-condensing)	0% to 95% (non-condensing)
Vibration (maximum)^*	0.66 GRMS	Not applicable
Shock (maximum)	110 G†	Not applicable
Altitude range	-15.2 m to 3048 m (-49.87 ft to 10,000 ft)	-15.2 m to 10,668 m (-49.87 ft to 35,000 ft)
CAUTION:Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components.

^{* Measured using a random vibration spectrum that simulates the user environment.}

^{† Measured using a 2 ms half-sine pulse.}

Dell Pro Education 11 PE11260 2-in-1: технические характеристики и спецификации
