Dell Chromebook 3100: технические характеристики и спецификации

Dimensions and weight

Table 1. Dimensions and weightThe following table provides the dimensions and weight specifications for your computer:
Feature Specifications

Height

Front: 20.75 mm (0.817 inches)

Rear: 20.75 mm (0.817 inches)

Width

303.9 mm (11.96 inches)

Depth

207.9 mm (8.19 inches)

Weight

For WiFi enabled systems - 1.29 kg (2.85 lbs)

For 4G LTE enabled systems - 1.33 kg (2.93 lbs)

Processor

NOTE: Processor numbers are not a measure of performance. Processor availability is subject to change and may vary by region/country.
Table 1. Processor specificationsProcessor specifications

Type

UMA Graphics

Discrete Graphics

Intel Celeron N4000 Dual core processor (6 W TDP, 2 core count/ 2 threads, 4 MB cache, 2.6 GHz) Intel UHD Graphics 600 No
Intel Celeron N4020 Dual core processor (6 W TDP, 2 core count/2 threads, 4M Cache, up to 2.8GHz) Intel UHD Graphics 600 No

Chipset

Table 1. ChipsetChipset
Feature Specifications

Chipset

 Integrated in the processor (6 W/4.5 W SDP Gemini Lake – Celeron)

DRAM bus width

 64-bit

FLASH EPROM

 16 MB

PCIe bus

 Internal PCIe

Operating system

Table 1. Operating systemThe following table provides the operating system specifications for your computer:
FeatureSpecifications

Operating systems supported

Google Chrome operating system

Memory

Table 1. Memory specificationsMemory specifications
FeatureSpecifications

Minimum memory configuration

 4 GB

Maximum memory configuration

4 GB

Type

LPDDR4 (On-board memory)

Speed

2400 MHz

External ports

The following table lists the external ports on your Chromebook 3100.

Table 1. External portsExternal ports
Description Specifications

Memory card reader

NA

USB
  • One USB 3.1 Gen 1 port (left-side)
  • One USB Type-C port with Power delivery (left-side)
  • One USB 3.1 Gen 1 port—optional (right-side, for WiFi enabled systems only)
  • One USB Type-C port with Power delivery (right-side, available for 4G LTE enabled systems, optional for WiFi enabled systems)

Security

Noble wedge lock slot

Audio

One Universal Jack (Global Headset Jack + microphone + line in support) port

Wireless module

Table 1. Wireless moduleWireless module
Specifications

Intel dual band wireless-AC 9560 802.11ac 160 MHz (2x2) Wi-Fi + Bluetooth 5 M.2 1216 solder down

WWAN module

Table 1. WWAN module (For 4G LTE enabled systems)The following table provides the specifications of the WWAN module.
Feature Specifications
Model number Dell DW5820e Intel 7360 LTE-A
Host interface M.2 3042 form factor
Network standard LTE FDD/TDD, WCDMA/HSPA+, GNSS/Beidou
Transfer rate Up to 450 Mbps DL/50 Mbps UL (Cat 9)
Operating Frequency Bands (1,2,3,4,5,7,8,11,12,13,17,18,19,20,21,26,28,29,30,38,39,40,41,66), HSPA+ (1, 2, 4,5, 8)
Data Rate
  • LTE FDD: 450 Mbps DL/50 Mbps UL (Cat 9)
  • LTE TDD: 347 Mbps DL/30 Mbps UL (Cat 9)
  • UMTS/HSPA+: UMTS 384 kbps DL/384 kbps UL
Power supply DC 3.135 V to 4.4 V, Typical 3.3 V
Antenna Diversity Supported
Radio On/Off Supported
Wake On Wireless Supported
Temperature
  • Normal operating temperature: -10°C to 55°C
  • Extended Operating temperature: -20°C to 65°C
Antenna connector
  • WWAN Main Antenna X 1
  • WWAN Diversity Antenna X 1

Audio

Table 1. Audio specificationsAudio specifications
FeatureSpecifications

Controller

Dialog DA7219

Stereo conversion

 Supported

Type

 High Definition Audio

Speakers

2

Internal Interface

I2S

External Interface

Digital microphone input on camera module

Headset combo jack (stereo headphones/microphone-in)

Internal speaker amplifier

Supported

External Speaker Amp

MAX98357A

External volume controls

Supported

Speaker output:

  • Average - 2 W
  • Peak - 2.5 W

Subwoofer output

Not supported

Microphone

Supported

Storage

Table 1. Storage specificationsStorage specifications

Type

Capacity

MMC Interface

Voltage

eMMC16 GBeMMC V5.13.3 V
eMMC32 GB eMMC V5.13.3 V

Keyboard

Table 1. Keyboard specificationsThe following table provides the keyboard specifications for your computer:
Feature Specifications

Number of keys
  • 74 (U.S. and Canada)
  • 75 (UK)
  • 76 (Brazil)
  • 78 (Japan)

Size
Full sized
  • X = 19.05 mm key pitch
  • Y = 18.05 mm key pitch

Backlit keyboard

No

Layout

QWERTY

Camera

Table 1. Camera specificationsCamera specifications
FeatureSpecifications
Camera typeHD fixed focus

Resolution

Still image: HD resolution 1280 x 720 (1 MP)

Video: HD resolution 1280 x 720 (1 MP)

Imaging rateUp to 30 frames per second
Sensor type

CMOS sensor technology

Touchpad

Table 1. Touchpad specificationsThe following table provides the touchpad specifications for your computer:
FeatureSpecifications

Resolution

1229 x 749

Dimensions

  • X-axis: 99.4 mm (3.91 inches)
  • Y-axis: 54.4 mm (2.14 inches)

Multi-touch

Supports five fingers

Power adapter

Table 1. Power adapter specificationsThe following table provides the power adapter specifications for your computer:
FeatureSpecifications

Type

Pecos 65 W USB-C

Input Voltage

100 VAC - 240 VAC

Input current (maximum)

1.7 A

Adapter size

Dimensions

In Inches: 1.1 x 2.01 x 4.41

In mm: 28 x 51 x 112

Weight

0.201 kg (0.443 lbs)

Input frequency

50 Hz to 60 Hz

Output current

20 V/3.25 A (continuous)

15 V/3 A (continuous)

9 V/3 A (continuous)

5 V/3 A (continuous)

Rated output voltage

20 VDC / 15 VDC / 9 VDC / 5 VDC

Temperature range (Operating)

0°C to 40° C (32°F to 104°F)

Temperature range (Non-Operating)

-40°C to 70°C (-40°F to 158°F)

Battery

Table 1. BatteryBattery
Feature Specifications

Type

3-cell lithium-ion (42 WHr)

3-cell Polymer (42 WHr)

Dimension

Width

Depth

Height

89.15 mm (3.50 inches)

175.47 mm (6.90 inches)

5.90 mm (0.23 inches)

Width

Depth

Height

89.15 mm (3.50 inches)

175.47 mm (6.90 inches)

5.90 mm (0.23 inches)

Weight (maximum)

0.185 kg (0.40 lb)

0.195 kg (0.42 lb)

Voltage

11.40 VDC

11.40 VDC

Life span

1 year

1 year

Operating time

Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions

Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions

Temperature range: Operating
  • 0°C to 35°C (32°F to 95°F)
  • Charge : 0 °C to 50 °C (32 °F to 122 °F)
  • Discharge: 0 °C to 70 °C (32 °F to 158 °F)
  • 0°C to 35°C (32°F to 95°F)
  • Charge : 0 °C to 50 °C (32 °F to 122 °F)
  • Discharge: 0 °C to 70 °C (32 °F to 158 °F)

Temperature range: Storage

- 20 °C to 65 °C (- 4 °F to 149 °F)

- 20 °C to 65 °C (- 4 °F to 149 °F)

Display

Table 1. Display specificationsDisplay specifications
Feature Specifications

Type

11.6 inch, HD TN Non-Touchscreen, and 187 Nits.

11.6 inch, HD TN Touchscreen, and 187 Nits (optional).

Height (Active area)

 144.00 mm

Width (Active area)

 256.125 mm

Diagonal

 293.83 mm (11.6 inches)

Megapixels

 1.04

Pixels Per Inch (PPI)

 135

Contrast ratio (Typical)

500:1

Refresh rate

 60 Hz

Horizontal viewing angle (min)

 +40/-40 degrees

Vertical viewing angle (min)

 +10/-30 degrees

Power consumption (max)

 3.0 W

GPU-integrated

Table 1. GPU-integrated specificationsGPU-integrated specifications

Controller

Type

CPU Dependency

Graphics memory type

Capacity

External display support

Maximum resolution

Intel UHD Graphics 600

UMA

Intel Celeron N4000 Dual core CPU

Integrated

Shared system memory

Supported via USB Type-C port

3840 x 2160 @60 Hz

Operating and storage environment

Table 1. Operating and storage environmentThis topic lists the operating and storage environment of Chromebook 3100.

Operating

Storage

Temperature range

 0°C to 35°C (32°F to 95°F) -40°C to 65°C (-40°F to 149°F)

Relative humidity (maximum)

 10% to 90% (noncondensing)
NOTE: Maximum dew point temperature = 26°C
0% to 95% (noncondensing)
NOTE: Maximum dew point temperature = 33°C

Vibration (maximum)

 2 to 600 Hz at 0.66 Grms 2 to 600 Hz at 1.33 Grms

Shock (maximum)

 160 G with pulse duration of 2 ms (equivalent to 80 in/sec) 160 G with pulse duration of 2 ms (equivalent to 80 in/sec)

Altitude (maximum)

 0 m to 3048 m (0 ft to 10,000 ft) 0 m to 10,668 m (0 ft to 35,000 ft)

Security

Table 1. SecuritySecurity
Feature Specifications

Trusted Platform Module (TPM) 2.0

Yes

Firmware TPM

NA

Cable lock

Wedge-type lock slot

Services and support

Table 1. Services and support specificationsServices and support:
FeatureSpecifications

1-Year Mail-In Service

Standard

Onsite NBD

NOTE: Service many be provided by third party. Technician will be dispatched if necessary following phone-based troubleshooting, subject to parts availability, and other terms of service contract.

Yes

Warranty Extensions

Up to 4 years

ProSupport

Optional

COO Label background color

Table 1. COO Label background color comparison tableChromebook 3100 has the COO label background color as Dark Grey. For 4G LTE enabled systems, the COO label background color is Titan Grey Dull.
Chromebook 3100 Chromebook 3100 (enabled with 4G LTE)
Chromebook 3100 has the COO label background color as Dark Grey. For 4G LTE enabled systems, the COO label background color is Titan Grey Dull.
