Dimensions and weight

The following table lists the height, width, depth, and weight of your Inspiron 14 5441.

Table 1. Dimensions and weight
The following table provides the detailed display specifications of Inspiron 14 5441.
Description		Values
Height:
Front height		15.14 mm (0.60 in.)
Rear height		16 mm (0.63 in.)
Maximum height		17.90 mm (0.70 in.)
Width		314 mm (12.36 in.)
Depth		223.75 mm (8.81 in.)
Weight NOTE:The weight of your computer depends on the configuration that is ordered and manufacturing variability.		1.54 kg (3.39 lb)

Processor

The following table lists the details of the processors that are supported for your Inspiron 14 5441.

Table 1. Processor
The following table provides the various processor options that are supported for Inspiron 14 5441.
Description	Option one	Option two	Option three
Processor type	Qualcomm Snapdragon X Plus X1P-42-100	Qualcomm Snapdragon X Plus X1P-64-100	Qualcomm Snapdragon X X1-26-100
Processor wattage	18 W	18 W	18 W
Processor total core count	8	10	8
Performance-cores	8	6	8
Efficient-cores	Not applicable	4	Not applicable
Processor total thread count	8	10	8
Processor speed	Up to 3.42 GHz	Up to 3.40 GHz	Up to 2.97 GHz
Performance-cores frequency
Processor base frequency	3.24 GHz	3.40 GHz	2.95 GHz
Maximum turbo frequency	3.42 GHz	3.40 GHz	2.97 GHz
Efficient-cores frequency
Processor base frequency	Not applicable	3.40 GHz	Not applicable
Maximum turbo frequency	Not applicable	3.40 GHz	Not applicable
Thermal Mode/Thermal Design Power (TDP)
Cool	13 W	13 W	13 W
Optimized	18 W	18 W	18 W
Quiet	12 W	12 W	12 W
Ultra Performance	21 W	21 W	21 W
NOTE: Processor clock speeds and thermal design power differ according to the thermal mode selected in the MyDell app on your computer.
Processor cache	30 MB	42 MB	30 MB
Neural Processing Unit (performance)	Up to 45 TOPS	Up to 45 TOPS	Up to 45 TOPS
Integrated graphics	Qualcomm Adreno	Qualcomm Adreno	Qualcomm Adreno

Chipset

The following table lists the details of the chipset that is supported by your Inspiron 14 5441.

Table 1. Chipset The following table lists the details of the chipset that is supported by your Inspiron 14 5441.
Description	Values
Chipset	Integrated with the processor
Processor	Qualcomm Snapdragon X Qualcomm Snapdragon X Plus
DRAM bus width	128-bit
Flash EPROM	64 MB
PCIe bus	Up to PCIe 4.0

Operating system

Your Inspiron 14 5441 supports the following operating systems:

Win 11 Home, ARM
Win 11 Pro, ARM

Memory

The following table lists the memory specifications of your Inspiron 14 5441.

Table 1. Memory specifications
The following table provides the detailed memory specifications of Inspiron 14 5441.
Description		Values
Memory slots		Onboard
Memory type		LPDDR5x
Memory speed		8448 MT/s
Maximum memory configuration		32 GB
Minimum memory configuration		16 GB
Memory configurations supported		16 GB: LPDDR5x, 8448 MT/s (onboard) 32 GB: LPDDR5x, 8448 MT/s (onboard)

External ports and slots

The following table lists the external ports and slots on your Inspiron 14 5441.

Table 1. External ports and slots
The following table lists ports and connectors available on Inspiron 14 5441.
Description	Values
USB ports	One USB 3.2 Gen 1 (5 Gbps) port Two USB4 40 Gbps USB Type-C port with DisplayPort and Power Delivery)
Audio port	One headset (headphone and microphone combo) port
Video port(s)	Not applicable
Media-card reader	One microSD-card slot
Power-adapter port	Not applicable
Security-cable slot	Not applicable

Internal slots

The following table lists the internal slots of your Inspiron 14 5441.

Table 1. Internal slotsThe following table lists the internal slots on your Inspiron 14 5441.
Description	Values
M.2	One M.2 2230 slot for solid state drive NOTE:To learn more about the features of different types of M.2 cards, search Dell Support Site.

Wireless module

The following table lists the Wireless Local Area Network (WLAN) module that is supported on your Inspiron 14 5441.

Table 1. Wireless module specifications
The following table provides the wireless module specifications of Inspiron 14 5441.
Description	Values
Model number	Qualcomm FastConnect 7800 DBS (onboard)
Transfer rate	Up to 5760 Mbps
Frequency bands supported	2.4 GHz/5 GHz/6 GHz
Wireless standards	WiFi 802.11a/b/g Wi-Fi 4 (WiFi 802.11n) Wi-Fi 5 (WiFi 802.11ac) Wi-Fi 6E (WiFi 802.11ax) Wi-Fi 7 (WiFi 802.11be)
Encryption	64-bit/128-bit WEP AES-CCMP TKIP
Bluetooth wireless card NOTE:The functionality of the Bluetooth wireless card may vary based on the operating system.	Bluetooth 5.4

Audio

The following table lists the audio specifications of your Inspiron 14 5441.

Table 1. Audio specifications
The following table provides the detailed audio specifications of Inspiron 14 5441.
Description		Values
Audio controller		Qualcomm WCD9385
Stereo conversion		Supported
Internal audio interface		SoundWire
External audio interface		Global headset audio jack
Number of speakers		2
Internal-speaker amplifier		Supported
External volume controls		Keyboard shortcut controls
Speaker output:
Average		2 W x 2
Peak		2.5 W x 2
Microphone		Dual-array microphones

Storage

This section lists the storage options on your Inspiron 14 5441.

Your computer supports only one M.2 2230 solid-state drive.

Table 1. Storage specifications
The following table provides the different storage options available on Inspiron 14 5441.
Storage type	Interface type	Capacity
One M.2 2230 solid state drive	PCIe NVMe 4x4	Up to 1 TB

Media-card reader

The following table provides the specification of media cards that are supported by your Inspiron 14 5441.

Table 1. Media-card reader specificationsThe following table provides the specification of media cards that are supported by your Inspiron 14 5441.
Description	Values
Media-card slot type	One microSD-card slot
Media-cards supported	Micro Secure Digital (mSD) Micro Secure Digital High Capacity (mSDHC) Micro Secure Digital Extended Capacity (mSDXC)
NOTE:The maximum capacity of the media-card reader varies depending on the standard of the media card that is inserted in your computer.

Keyboard

The following table lists the keyboard specifications of your Inspiron 14 5441.

Table 1. Keyboard specifications
The following table provides the detailed keyboard specifications of Inspiron 14 5441.
Description	Values
Keyboard type	Backlit keyboard with Copilot key Non-backlit keyboard with Copilot key
Keyboard layout	QWERTY
Number of keys	Arabic, English International, English US, Canadian Bilingual, Hebrew: 79 keys Belgian, English UK, French European, German, Hungarian, Italian, Spanish, Swiss European: 80 keys Japanese: 83 keys Brazilian: 81 keys
Keyboard size	X=19.05 mm key pitch Y=18.05 mm key pitch
Keyboard shortcuts	Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. To type the alternate character, press Shift and the required key. To perform secondary functions, press Fn and the desired key. NOTE:You can define the primary behavior of the function keys (F1–F12) changing Fn Lock Options in BIOS setup program. For more information, see Keyboard function keys. NOTE: If Copilot in Windows is not available on your computer, the Copilot key launches Recall. If both Recall and Copilot in Windows are not available on your computer, the Copilot key launches Windows Search. For more information about Copilot in Windows and Recall, search in the Knowledge Base Resource at the Dell Support Site.

Keyboard function keys

NOTE:Keyboard characters may differ depending on the keyboard language configuration. Keys that are used for shortcuts remain the same across all language configurations.

Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. The symbol that is shown on the lower part of the key refers to the character that is typed out when the key is pressed. If you press shift and the key, the symbol that is shown on the upper part of the key is typed out. For example, if you press 2, 2 is typed out; if you press Shift + 2, @ is typed out.

The keys F1-F12 at the top row of the keyboard are function keys for multimedia control, as indicated by the icon on the key. Press the function key to invoke the task represented by the icon. For example, pressing F1 mutes the audio (see the table below).

However, if the function keys F1-F12 are needed for specific software applications, multimedia functionality can be disabled by pressing Fn + Esc. Later, multimedia control can be invoked by pressing fn and the respective function key. For example, mute audio by pressing fn + F1.

Table 1. Primary behavior of function keys
The following table lists the keyboard shortcuts and their descriptions.
Function key	Primary behavior
F1	Mute/unmute audio
F2	Decrease audio volume
F3	Increase audio volume
F4	Play or pause media file
F5	Turn on or turn off keyboard backlight (optional)
F6	Decrease display brightness
F7	Increase display brightness
F8	Switch to an external display
F10	Print screen (screen capture)
F11	Move cursor to the beginning of the line
F12	Move cursor to the end of the line
Copilot	Launch Copilot in Windows NOTE: If Copilot in Windows is not available on your computer, the Copilot key launches Recall. If both Recall and Copilot in Windows are not available on your computer, the Copilot key launches Windows Search. For more information about Copilot in Windows and Recall, search in the Knowledge Base Resource at the Dell Support Site.

The fn key is also used with selected keys on the keyboard to invoke other secondary functions.

Table 2. Secondary behaviorThe following table lists the secondary behavior of each key with the Function (fn) key.
Function key	Secondary behavior
fn + F1	Operating system and application-specific F1 behavior
fn + F2	Operating system and application-specific F2 behavior
fn + F3	Operating system and application-specific F3 behavior
fn + F4	Operating system and application-specific F4 behavior
fn + F5	Operating system and application-specific F5 behavior (optional)
fn + F6	Operating system and application-specific F6 behavior
fn + F8	Operating system and application-specific F8 behavior
fn + F9	Operating system and application-specific F9 behavior
fn + F10	Operating system and application-specific F10 behavior
fn + F11	Operating system and application-specific F11 behavior
fn + F12	Operating system and application-specific F12 behavior
fn + B	Pause or Break
fn + S	Toggle scroll lock
fn + R	System request
fn + Copilot	Open the application menu
fn + Esc	Toggles the function key on and off
fn + PgUp	Scroll up the document or page
fn + PgDn	Scroll down the document or page
fn + left arrow	Home (move to the beginning of the document)
fn + right arrow	End (move to the end of the document)

Camera

The following table lists the camera specifications of your Inspiron 14 5441.

Table 1. Camera specifications
The following table provides the detailed camera specifications of Inspiron 14 5441.
Description			Values
Number of cameras			Two
Camera type			FHD Infrared camera with Ambient Light Sensor (ALS)
Camera location			Front
Camera sensor type			CMOS sensor technology
Camera resolution:
Still image			2.07 megapixel
Video			1920 x 1080 (FHD) at 30 fps
Infrared camera resolution:
Video			1280 x 720 (HD) at 30 fps
Diagonal viewing angle:
Camera			80.2 degrees
Infrared camera			86.6 degrees

Touchpad

The following table lists the touchpad specifications of your Inspiron 14 5441.

Table 1. Touchpad specifications
The following table provides the detailed touchpad specifications of Inspiron 14 5441.
Description		Values
Touchpad resolution:		>300 DPI
Touchpad dimensions:
Horizontal		115 mm (4.53 in.)
Vertical		80 mm (3.15 in.)
Touchpad gestures		For more information about the touchpad gestures available on Windows, search Microsoft Support Site.

Power adapter

The following table lists the power adapter specifications of your Inspiron 14 5441.

Table 1. Power-adapter specifications
The following table provides the detailed power adapter specifications of Inspiron 14 5441.
Description	Values
Type	65 W
Power-adapter dimensions:
Height	28 mm (1.10 in.)
Width	51 mm (2.01 in.)
Depth	112 mm (4.41 in.)
Input voltage	100 VAC–240 VAC
Input frequency	50 Hz–60 Hz
Input current (maximum)	1.70 A
Output current (continuous)	20 V/3.25 A 15 V/3 A 9 V/3 A 5 V/3 A
Rated output voltage	20 VDC 15 VDC 9 VDC 5 VDC
Temperature range:
Operating	0°C to 40°C (32 °F–104°F)
Storage	40 °C–70°C (40 °F–158°F )
CAUTION:Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components.

Power adapter requirements of Inspiron 14 5441

NOTE:If you did not purchase the Dell-branded power adapter that is recommended for your computer, ensure that the power adapter you use meets the following requirements.

The following table lists the power adapter requirements for your Inspiron 14 5441.

Table 1. Power adapter requirements Inspiron 14 5441 power adapter requirements.
Description	Value
Power that is required from a power adapter to achieve optimal performance.	65 W
Power that charges the computer at a slower speed. NOTE:A warning message may appear informing you about the use of a lower-powered adapter and slower charging speed.	Less than 60 W
Minimum power that is required from a power adapter to operate the computer and charge the battery. NOTE:A warning message appears informing you about the use of a lower-powered adapter and slower charging speed.	27 W
USB Power Delivery (PD) fast charging.	Supported
ExpressCharge mode	Supported NOTE:Ensure that the computer is connected to a 65 W power adapter for this feature to be supported. NOTE:ExpressCharge mode must also be enabled in the BIOS Setup screen. Select Power > Battery Configuration > ExpressCharge, then press Enter.

Battery

The following table lists the battery specifications of your Inspiron 14 5441.

Table 1. Battery specifications
The following table provides the detailed battery specifications of Inspiron 14 5441.
Description		Values
Battery type		3-cell, 54 Wh, lithium-ion, Long Cycle Life + ExpressCharge
Battery voltage		11.4 VDC
Battery weight (maximum)		0.22 kg (0.49 lb)
Battery dimensions:
Height		5.73 mm (0.23 in.)
Width		263 mm (10.35 in.)
Depth		68.90 mm (2.71 in.)
Temperature range:
Operating		Charge: 0 °C–45 °C (32 °F–113 °F) Discharge:0 °C–70 °C (32 °F–158 °F)
Storage		–20 °C–65 °C (4 °F–149 °F )
Battery operating time		Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions.
Battery charging time (approximate)		3 hours (Standard charge) 2 hours (ExpressCharge)
Coin-cell battery		CR2032
CAUTION:Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components. CAUTION:Dell Technologies recommends that you charge the battery regularly for optimal power consumption.

Power requirements (for computers shipped with 3-cell, 54 Wh battery)

NOTE: The information in this section is applicable to the European Union (EU) countries.

Image: Pictogram for 54 Wh battery — Figure 1. Pictogram for 54 Wh battery

The power that is delivered by the charger must be between a minimum of 27 Watts that is required by the radio equipment, and a maximum of 65 Watts in order to achieve the maximum charging speed.

This computer supports USB Power Delivery (PD) fast charging.

Display

The following table lists the display specifications of your Inspiron 14 5441.

Table 1. Display specificationsThe following table provides the detailed display specifications of your Inspiron 14 5441.
Description		Values
Display type		14", Full High Definition Plus (FHD+)
Touch options		No
Display-panel technology		Wide Viewing Angle (WVA)
Display-panel dimensions (active area):
	Height	188.49 mm (7.42 in.)
	Width	301.59 mm (11.87 in.)
	Diagonal	355.65 mm (14 in.)
Display-panel native resolution		1920 x 1200
Luminance (typical)		300 nits
Megapixels		2.3
Color gamut		45% NTSC
Pixels Per Inch (PPI)		162
Contrast ratio (minimum)		600:1
Response time (maximum)		35 millisecond
Refresh rate		60/48 Hz
Horizontal view angle		85 +/- degrees
Vertical view angle		85+/- degrees
Pixel pitch		0.1178 mm
Power consumption (maximum)		3.68 W
Anti-glare vs glossy finish		Anti-glare

Fingerprint reader (optional)

The following table lists the specifications of the optional fingerprint-reader of your Inspiron 14 5441.

Table 1. Fingerprint reader specifications
The following table provides the specifications of fingerprint reader of Inspiron 14 5441.
Description	Values
Sensor technology	Capacitive
Sensor resolution	500 ppi
Sensor pixel size	108 x 88

GPU—Integrated

The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your Inspiron 14 5441.

Table 1. GPU—Integrated
The following table provides the detailed integrated graphics specifications of Inspiron 14 5441.
Controller	Memory size	Processor
Qualcomm Adreno Graphics	Shared system memory	Qualcomm Snapdragon X X1-26-100 Qualcomm Snapdragon X Plus X1P-42-100 Qualcomm Snapdragon X Plus X1P-64-100

External display support

The following table lists the external display support for your Inspiron 14 5441.

Table 1. External display supportThe following table lists the external display support for your Inspiron 14 5441.
Graphics card	Supported external displays with laptop display enabled	Supported external displays with laptop display disabled
Qualcomm Adreno Graphics (iGPU only)	3	3

Operating and storage environment

This table lists the operating and storage specifications of your Inspiron 14 5441.

Airborne contaminant level: G1 as defined by ISA-S71.04-1985

Table 1. Computer environment
The following table lists the operating and storage environment conditions of Inspiron 14 5441.
Description	Operating	Storage
Temperature range	0 °C–35°C (32 °F–95°F)	–30 °C–65°C (–22 °F–149°F)
Relative humidity (maximum)	10% to 90% (non-condensing)	0% to 95% (non-condensing)
Vibration (maximum)^*	0.66 GRMS	1.30 GRMS
Shock (maximum)	110 G†	160 G†
Altitude range	–15.2 m to 3048 m (–49.87 ft to 10,000 ft)	–15.2 m to 10,668 m (–49.87 ft to 35,000 ft)
CAUTION:Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components.

^{* Measured using a random vibration spectrum that simulates the user environment.}

^{† Measured using a 2 ms half-sine pulse.}

Dell support policy

For information about Dell support policy, search Dell Support Site.
